TATA Hitachi TH 76 Backhoe Loader Price in India 2022, Specification, Overview

Guys!! Are you thinking to buy TATA Hitachi TH 76 Backhoe Loader? And do you want to know about that Price, Key features, Hydraulic system, Transmission system, Axles, images and more? if yes, then don’t worry my friends, cause Here in this article of mine, I am going to present that all kinds of information which you need to know about it.

TATA Hitachi TH 76 Backhoe Loader features

The TATA Hitachi TH 76 Backhoe Loader some main features such as Reinforced for Longer life, Rain forced Link for stronger, Havey duty excavator type arm, Clutchless gear shifting for easy to drive, Cyclonic air pre-cleaner for low maintenance, Reinforced loader bucket for longer life, Bolt-on type tooth point for easy to change, Adjustable wear pads for precise excavator movement. It’s more information you can check in that below specification table friends.

You May also like to check:

TATA Hitachi TH 76 Backhoe Loader Price in India

The TATA Hitachi TH 76 Backhoe Loader Price starts at 10 Lakh. And for any inquiry please contact us on this toll-free number 1800 3456 500.

You may also read: TATA Hitachi TH 86 Backhoe Loader.

TATA Hitachi TH 76 Backhoe Loader Quick Facts

  • Model Code:  TH 76
  • Engine Power:  76 PS
  • Operating Weight: 7350 kg
  • Bucket Capacity: Backhoe : 0.09 – 0.25 m3  | Loader : 1 m3
  • BS III compliant, 4 Cylinder, water cooled, Turbocharged engine

TATA Hitachi TH 76 Backhoe Loader Specifications

TATA Hitachi TH 76 Backhoe Loader specs

ENGINE
Make & ModelTATA 497 TCIC
TypeTurbo-Charged, Inter-Cooled 4 Cylinder Diesel Engine
Gross Power76 PS @ 2200 rpm
Max.Torque28 kg-m @ 1300-1700 rpm
Battery12 V-130 AH
TRANSMISSION
TH 76 is provided with fully Powershift transmission sourced from the internationally renowned ZF, with heavy duty clutch packs for smooth and easy gear shift.
The integral Torque converter has stall ratio of 1:2.63 which increases the tractive effort, making dozing operation easy in tough conditions. Powershift transmission facilitates “on the move clutchless gear shift” through the click of the knob both in forward and reverse direction.
TURNING RADIUS 2WD
Curb turning circle:
With brakes7140 mm
Without brakes8808 mm
Bucket clearance circle:
With brakes9610 mm
Without brakes10500 mm
REFILL CAPACITY
Fuel tank (with ground level fueling)136.0 ltr
Engine coolant21.9 ltr
Engine oil including filter9.0 ltr
Transmission13.0 ltr
Hydraulic system91.0 ltr
Rear axle16.0 ltr
TYRES
Front Tyres (standard)9-16, 16 PR
Rear Tyres
(standard)…Industrial tyres16.9-28, 12 PR
(standard)…Heavy duty tyres14-25, 20 PR
AXLE
Front AxleThe rigid non-powered front axle for two-wheel drive version can float 18Deg. to take care of unevenness of the ground.
Rear AxleRear ZF Multitrac Axle is a heavy duty, long-life axle


 TATA Hitachi TH 76 Backhoe Loader specs

TRAVEL SPEEDS
Travel speeds with the standard rear center. (16.9-28, 12 PR)
 ForwardReverse
Gear 16 kmph7 kmph
Gear 210 kmph13 kmph
Gear 321 kmph
Gear 436 kmph


TATA Hitachi TH 76 Backhoe Loader price

BUCKETS
Loader EndWidthCapacityWeight
Tilt dump bucket2346 mm1.00 m3522 kg

Backhoe EndWidthCapacityWeight
General purpose bucket711 mm0.25 m3193 kg
Heavy-duty bucket610 mm0.22 m3180 kg


TATA Hitachi TH 76 Backhoe Loader 7

Loader PerformanceBucket Types
Tilt Dump BucketBottom Dump (6-in-1) Bucket
Break force4140 kgf3765 kgf
Lifting capacity, full height2790 kg2631 kg
Height to bucket hinge pin, maximum3400 mm3400 mm
. Dump clearance, bucket at 45Deg.2640 mm2620 mm
Bucket dump angle, maximum45Deg.45Deg.
Reach at full height, bucket at 45deg.765 mm818 mm
Rollback angle at ground level40Deg.40Deg.
Digging depth below ground, bucket level206 mm185 mm
Max. Operating height3820 mm3820 mm

Backhoe PerformanceBoom Length: 2.56 m
Digging force, bucket cylinder : 5300 kgf Digging force, arm cylinder : 3200 kgf*Arm Length 1.72 m
Loading height, truck loading position3560 mm
Max. Reach from the center of swing point at a ground5415 mm
Reach from center of rear axle6841 mm
Maximum digging depth4248 mm
Digging depth
(E1) 610 mm flat bottom4200 mm
(E2) 2440 mm flat bottom3890 mm
Ground clearance, minimum350 mm
Bucket rotation184 deg.
Transport height3670 mm
Overall length, transport5210 mm
Side-shift from tractor centerline532 mm
Wall to swing center line580 mm
Stabilizer width2235 mm
Lift capacity to bucket pivot1699 kg
Maximum cutting height:
(stab. full open)5750 mm
(stab. closed)5250 mm
Total side shift travel1050 mm
Max. side reach (with side shift) from center of machine5878 mm
