TATA Hitachi ZAXIS 220 LC-M Gi Series Price in India, Specifications, Features, Overview

TATA Hitachi ZAXIS220LC GI Series excavator gives state-of-the-art Japanese technology that has proven itself in the bulk mining and in the quarry part. With a refined Isuzu engine, excellent productivity, premium driver comfort, fuel efficiency, beautiful looks, versatility and strong structure, it gives the highest returns on investment.

TATA Hitachi ZAXIS 220 LC-M Machinery price

Are you planning to buy TATA Hitachi Zaxis 220LC-M GI Series Construction Machinery? And do you want to know about TATA Hitachi Zaxis 220LC-M GI Price, Key features, Hydraulic system, Digging forces, Undercarriage, images, and more? if yes, then don’t worry my friends, cause Here in this article of mine, I am going to present that all kinds of information which you need to know about it.

Also Check:

TATA Hitachi Zaxis 220LC-M GI Series Price in India

TATA Hitachi ZAXIS 220 LC-M Machinery specs The TATA Hitachi Zaxis 220LC-M GI Series Construction Machinery price Starts at Rs 61.76 Lakh

TATA Hitachi ZAXIS 220LC-M GI Series Construction Machinery Quick Facts

TATA Hitachi ZAXIS 220 LC-M Machinery 1

  • Model Code: ZAXIS 220 LC -M GI Series
  • Engine Rated Power: 163 PS
  • Operating Weight: 20,900 kg
  • Bucket Capacity: 0.45 – 1.0 m3

TATA Hitachi Zaxis 220LC-M GI Series Specifications

ENGINE
Model Mitsubishi S6K-TA61MHTA
Type 4-cycle water-cooled, direct injection
Aspiration Turbocharged (With charged air cooler)
No. of cylinders 6
Rated power:
Full load 163 PS (120 kW) at 2000 rpm
Working load 155 PS (114 kW) at 1800 rpm
Maximum torque 655 Nm @ 1500 rpm
Piston displacement 6.494 L
Bore and stroke 102 mm x 125 mm
Batteries 2 x 12 V / 88 Ah
HYDRAULIC SYSTEM
Hydraulic Pumps
Main pumps 2 variable displacement axial piston pumps
Maximum oil flow 2 x 212 L/min
Pilot pump 1 gear pump
Maximum oil flow 33.6 L/min
Relief Valve settings
Implement Circuit 350 kgf/cm2 (34.3 MPa)
Swing Circuit 310 kgf/cm2 (30.4 MPa)
Travel Circuit 350 kgf/cm2 (34.3 MPa)
Pilot Circuit .40 kgf/cm2 (3.9 MPa)
Power boost 388 kgf/cm2 (38.0 MPa)
UNDERCARRIAGE
NUMBERS OF ROLLERS AND SHOES ON EACH SIDE
Upper roller 2
Lower rollers 8 : ZX220LC-M (STD / QR)
Track shoes 49 : ZX220LC-M (STD / QR)
Track guard 2 : ZX220LC-M (STD) 3 : ZX220LC (QR)
TRAVEL DEVICE
Travel speeds High : 0 to 5.5 km/h Low : 0 to 3.5 km/h
Gradeability 70% (35 DEG. continuous)
Maximum Traction force 184 kN (18800 kgf)
REFILL CAPACITIES
Fuel tank capacity 400.0 L
Engine coolant  23.0 L
Engine oil 25.0 L
Swing device 6.2 L
Travel device (each side) 6.8 L
hydraulic system 240.0 L
Hydraulic tank 135.0 L
UPPERSTRUCTURE
Swing speed 13.0 min-1 (rpm)
Swing torque 60.4 kNm (6200 kgfm)




WORKING RANGES (MM)
Arm length 2.20 m 2.42 m 2.91 m
Max. digging reach 9260 9430 9920
Max. digging reach (on ground) 9080 9250 9750
Max. digging depth 5920 6120 6610
Max. digging depth (8’ level) 5680 5890 6420
Max. cutting height 9250 9330 9680
Max. dumping height 6450 6520 6850
Min. dumping height 3210 3010 2490
Min. swing radius 3530 3520 3490
Max. vertical wall digging depth 5420 5620 6030


 TATA Hitachi ZAXIS 220 LC-M Machinery price

DIMENSIONS
 Distance between tumblers 3660 mm
 Under carriage length 4460 mm
Counterweight clearance 1040mm
Rear-end swing radius 2910mm
Rear end length 2910 mm
Overall width of upper structure 2700 mm
Overall height cab 2940mm
Overall height of upperstructure 3010 mm
Minimum ground clearance 450 mm
Track gauge 2390 mm
Track shoe width 600 mm
Undercarriage width 2390 mm
Overall width 2990 mm
Track height with triple grouser shoes 920 mm
Overall length
With 2.20 m arm 9760 mm
With 2.42 m arm 9680 mm
With 2.91 m arm 9680 mm
Overall height of boom 3150 mm
With 2.20 m arm 3050mm
With 2.42 m arm 3010 mm
With 2.91 m arm 3050 mm




GROUND PRESSURE
Shoe Width Arm Length KPa (kgf/cm2)
600 mm 2.42 m 84 (0.49)




BUCKET AND ARM DIGGING FORCES
Arm Length 2.22 m 2.42 m 2.91 m
Bucket digging force 158 KN(16100 KGF) 158 kN (16100 kgf) 158 kn (16100 kgf)
Arm crowd force ISO 147 KN (15000 KGF) 139 kN (14200 kgf) 114 kn (11600 kgf)


Final Words

That was all about The TATA Hitachi Zaxix 220LC-M GI Series Construction. I hope you like this article, but if you have any questions regarding this article, then please comment below in the comment box my friends, And Stay with me for new TATA Hitachi Construction machinery information. Thanks for visiting our site friends.
