TATA Hitachi TMX20 Price, Specifications & Features
TATA Hitachi TMX20 Mini Excavators Price in India, Specification, Review, Overview
TATA Hitachi TMX20 is the smallest mini-excavator designed in India. Its small footprint and boom swing accounts for its compact dimension provide to access narrow areas. Its main features such as Very easy to transport, Frugal 28 hp engine, best in class power, superior digging forces for meeting the difficult challenges of worksites.
Are you searching for the TATA Hitachi TMX20 Construction Machinery? And do you want to know about TATA Hitachi TMX20 Price List, Technical specifications, Key Features, Images and more? if yes, then don’t worry my friends, cause Here in this article, I am going to present that all kinds of information which you need to know about it.
TATA Hitachi TMX20 Mini Excavators Construction Machinery Price
The TATA Hitachi TMX20 Mini Excavators price is Rs 24.14 Lakh
TATA Hitachi TMX20 Mini Excavators Construction Machinery Quick Facts
- Model Code: TMX 20 Super Series
- Engine Power: 28 HP
- Operating Weight: 2,200 Kg
- Bucket Capacity: 0.04 – 0.12 m3
TATA Hitachi TMX20 Mini Excavator Specifications
| ENGINE | |
| Make | Simpson |
| Model | S217 |
| Type | Water cooled. 2 cyl. inline |
| Rated flywheel power | 28 PS @ 2000 rpm |
| Maximum torque | 10.9 kgf-m @ 1400 rpm |
| Battery | 12 V |
| SUPER STRUCTURE | |
| Swing Speed | 11 rpm |
| Boom Swing Angle Standard | Left 50°, Right 90° |
| Boom Swing Angle Optional | Left 90°, Right 50° |
| HYDRAULIC SYSTEM | |
| Main Pumps | One Gear pump |
| Flow Rate | 63.6 lpm |
| RELIFE VALVE SETTINGS | |
| Implement Circuit | 150 kgf/cm2 |
| Swing Circuit | 145 kgf/cm2 |
| Travel Circuit | 150 kgf/cm2 |
| Pilot Circuit | 25 kgf.cm2 |
| UNDERCARRIAGE | |
| Shoe Width | 280 mm |
| No. of Trake Shoes | 36 x 2 |
| No. of Upper Rollers | 1 x 2 |
| No. of Lower Rollers | 3 x 2 |
| SERVICE REFILL CAPACITIES | |
| Hydraulic System | 70 ltr |
| Hydraulic Tank | 45 ltr |
| Fuel Tank | 37 ltr |
| Engine coolent | 7.5 ltr |
| Engine Oil | 05 ltr |
| Travel Device(Each side) | 0.8 ltr |
| WEIGHTS AND GROUND PRESSURE | |
| Operating Weight | 2300 kg |
| Ground Pressure | 0.30 kg/cm2 |
| BACKHOE ATTACHMENT | |
| BOOM | 1900 mm |
| Arm | 1000 mm |
| DIGGING FORCES | |
| Arm crowd force | 1300 kgf |
| Bucket digging force | 1890 kgf |
| BUCKETS | ||||
| CAPACITY (PCSA) | Width with side cutters | With w/o side cutters | Weight | No. of tooth points |
| 0.03 M3 | 350 mm | 310 mm | 42.5 kg | 3 |
| 0.07 M3 | 530 mm | 490 mm | 55 kg | 4 |
| 0.09 M3 | 530 mm | 490 mm | 66 kg | 4 |
| 0.12 M3 | – | 535 mm | 71. 3 kg | 0 |
