TATA Hitachi TH 86 L Wheel Loader Price, Specification & Features

TATA Hitachi TH 86 L Wheel Loader Price in India 2024, Specification, Review, Overview

A versatile variant of the TATA Hitachi TH 86 L Wheel Loader, this Wheel Loader is focused on loader application. With transmission system and axle from similar make to the ones used in wheel loader, the TATA Hitachi TH 86 L Wheel Loader helps produce excellent loader performance.

TATA Hitachi TH 86 L Wheel Loader price

Do you know about the TATA Hitachi TH 86 L Wheel Loader Price in India, Key features, Hydraulic system, Transmission, Refill Capacities, Travel Speeds, Axles, images and more? if yes, then don’t worry my friends, cause Here in this article of mine, I am going to present that all kinds of information which you need to know about it.

You May also like to check:

TATA Hitachi TH 86 L Wheel Loader Price in India

TATA Hitachi TH 86 L Wheel Loader 1

The TATA Hitachi TH 86 L Wheel Loader Price starts at Rs.30 Lakh. And for any inquiry please contact us on this toll-free number 1800 3456 500.

TATA Hitachi TH 86 L Wheel Loader Quick Facts

  • Model Code:  TH 86 L
  • Engine Power:  86 PS
  • Operating Weight: 7500 kg
  • Bucket Capacity: Backhoe: 1.0 – 1.2 m3
  • Turbocharged, Inter cooled 4 cylinder Diesel engine.

TATA Hitachi TH 86 L Wheel Loader Specifications

TATA Hitachi TH 86 L Wheel Loader specs

ENGINE
Make & ModelTATA 497 TCIC
TypeTurbo-Charged, Inter-Cooled 4 Cylinder Diesel Engine
Gross Power86 PS @ 2200 rpm
Max.Torque31 kg-m
Battery12 V-130 AH
TRANSMISSION
TH 86 L is provide with fully Powershift transmission sourced from the internationally renowned ZF, with heavy duty clutch packs for a smooth and easy click of the knob gear shift. The integral Torque converter has stall ratio of 1:2.63 which increases the tractive effort, making dozing operation easy in tough conditions
REFILL CAPACITY
Fuel tank (with ground level fueling)136.0 ltr
Engine coolant21.9 ltr
Engine oil including filter9.0 ltr
Transmission13.0 ltr
Hydraulic system91.0 ltr
Rear axle16.0 ltr
Front Wheel (only for4WD)8.0 ltr
TYRES
Front Tyres (standard)9-16, 16 PR | 12.5-8, 12 PR (Optional)
Rear Tyres
(standard)…Industrial tyres16.9-28, 12 PR
(standard)…Heavy duty tyres14-25, 20 PR
AXLE
Front AxleThe rigid non-powered front axle for two wheel drive version can float 180 deg. to take care of unevenness of ground.
Rear AxleRear ZF Multitrac Axle is a heavy duty, long-life axle
TURNING RADIUS 2WD
Curb turning circle
With brakes7868 mm
Without brakes8808 mm
Bucket clearance circle
With brakes9560 mm
Without brakes10500 mm
TRAVEL SPEEDS
Travel speeds with standard rear tyres. (16.9-28, 12 PR)
 ForwardReverse
Gear 16 kmph7 kmph
Gear 210 kmph13 kmph
Gear 321 kmph21 kmph
Gear 436 kmph
HYDRAULIC SYSTEM
Efficient hydraulic system with gear type TANDEM heavy duty pump
 Flow @ 2200 rpmPressure
Loader106 lpm210 bar
Filter
Return oil, spin-on type, replaceable, 10-micron element
BUCKETS
Loader EndWidthCapacityWeight
Tilt dump bucket2346 mm1.00 m3555 kg
Bottom dump (6-in-1) bucket2350 mm1.00 m3640 kg
Loader PerformanceBucket Types
Tilt Dump BucketBottom Dump (6-in-1) Bucket
Break force4140 kgf3765 kgf
Lifting capacity, full height2790 kg2631 kg
Height to bucket hinge pin, maximum3400 mm3400 mm
Dump clearance, bucket at 45Deg.2640 mm2620 mm
Bucket dump angle, maximum45Deg.45Deg.
Reach at full height, bucket at 45deg.765 mm818 mm
Rollback angle at ground level40Deg.40Deg.
Digging depth below ground, bucket level206 mm185 mm
Max. Operating height3820 mm3820 mm

Final Words For TATA Hitachi TH 86 L Wheel Loader

That was all about the TATA Hitachi TH 86 L Wheel Loader, I hope you like this article, but if you have any query about this article, then please comment below in the comment box my friends, we will solve your problem as soon as. And Stay tuned with me for more stuff like this. Thanks for visiting our site friends.
