TATA Hitachi EX 110 Super Price, Specification & Features

TATA Hitachi EX 110 Super Series Excavator Price in India, Specifications, Review, Overview

The TATA Hitachi EX 110 Super Series excavator is popular for its performance, giving great value for money and high returns on investment. This TATA Hitachi EX 110 machine gives superior fuel and operational economy while offering great production.

TATA Hitachi EX 110 Super Series specs

The TATA Hitachi EX 110 Super Series Construction Machinery designed with this main features such as wiper and window washer, Seat screw for front grill, Larger pin diameter, Reinforced arm plate, Reinforced boom end bracket, Cushioned cylinders, Larger boss diameter, excellent visibility roomy cab, High-temperature hoses and seals, And reinforced idler mounting frame hardened lubricated idlers and forged idler bearing. It’s more specification you can check in that below specification table.
TATA Hitachi EX 110 Super Series 1

Guys!! Are you thinking to buy TATA Hitachi EX 110 Super Series Machinery? And do you want to know about that Price, Key features, Hydraulic system, Digging forces, Undercarriage, images and more? if yes, then don’t worry my friends, cause Here in this article of mine, I am going to share with you that all kinds of information which you need to know about it.

Also Check:

TATA Hitachi EX 110 Super Series Quick Facts

TATA Hitachi EX 110 Super Series specs

  • Model Code: EX 110 Super Series
  • Engine Power: 76 PS
  • Operating Weight: 11,000 kg
  • Bucket Capacity: 0.25 – 0.65 m3
  • Also: Check:  TATA Hitachi TH 76 Backhoe Loader

TATA Hitachi EX 110 Super Series Walkaround Video

TATA Hitachi EX 110 Super Series Price

TATA Hitachi EX 110 Super Series price The TATA Hitachi EX 110 Super Series price Starts at 20 Lakh

TATA Hitachi EX 110 Super Series Specifications

ENGINE
Model TATA 697 NA
Type Water cooled, 6 cylinder in-line diesel engine
Engine power 76 ps @ 2200 rpm
Maximum Torque 25.4 kgfm @ 2000 rpm
Batteries 2 x 12 v
HYDRAULIC SYSTEM
Main pumps 2 variable displacement axial piston pumps
Flow rate 2 x 115 Lpm
Pilot pump 1 gear pump
Flow rate 23 lpm
SUPER STRUCTURE
Swing speed 11.8 rpm
UNDERCARRIAGE
Travel speeds 0-4.3 kmph
Gradeability 30deg (75% continuous)
Maximum Traction force 7500 kgf
No. of upper rollers (each side) 1
No. of lower rollers (each side) 6
No. of track shoes (each side) 41
Shoe wish 500 mm
SERVICE REFILL CAPACITIES
Hydraulic Tank 72.0 L
Hydraulic system 125.0 L
Fuel tank 250.0 L
Engine coolant 11.0 L
Engine oil 14.0 L
Swing device 3.2 L
Travel device (each side) 3,5 L
RELIEF VALVE SETTINGS
Implement circuit 286 kgf /cm3
Swing circuit 286 kgf /cm3
Travel circuit 355 kgf /cm3
Pilot circuit 40 kgf /cm3
DIGGING FORCES
BACKHOE
Bucket digging force 7300 kgf
Arm crowd force 5400 kgf
SHOWEL
Maximum breakout force  7250 kgf
Maximum crowding force 7900 kgf
BACKHOE
BOOM LENGTH 4250
ARM LENGTH 1560
Maximum digging reach 7410
Maximum digging reach (on ground) 7250
Maximum digging depth 4720
Maximum cutting height 4460
Maximum dumping reach 7360
Maximum swing radius 2460
SHOVEL
BOOM LENGTH  2500
ARM LENGTH 2000
Maximum digging reach 5500
Maximum cutting height 6750
Maximum dumping height 3290
Maximum digging depth 2620
Working radius at dumping height 2630


TATA Hitachi EX 110 Super Series price

WEIGHT AND GROUND PRESSURE
Machine Operating weight Ground pressure
Backhoe 11600 kg 0.40 kgf /cm3
Shovel 11600 kg 0.40 kgf /cm3


TATA Hitachi EX 110 Super Series price Final Words

I hope you like this article, but if you have any queries about this article, then please comment below in the comment box my friends, we will solve your problem as soon as. And stay with me for new Construction machinery information. You can also check TATA Hitachi Mini Excavators other model information on our site. Thanks for visiting our site friends.
