TATA Hitachi EX 210 LC Super Series Machinery Price Specs Overview
The TATA Hitachi EX 210 LC is India’s high rated hydraulic excavator. TATA Hitachi EX 210 LC offers a high return on investment and comes with excellent hydraulics, power optimization and efficiency boosters. TATA Hitachi EX 210 LC hydraulic excavator is very easily serviceable and is recognized for its performance.
TATA Hitachi EX 210 LC Super Series Machinery designed with this main features such as Rain forced idler mounting frame hardened lifetime lubricated idlers and forged idler bearing, Wiper and window washer, front grill, Larger pin diameter, Reinforced arm plate, Reinforced boom-end bracket, Cushioned cylinder, Larger boss diameter, Powerful cummies 6BT5.9c engine, cyclonic pre-cleaner.
Here This article of mine I am going to introduce the TATA Hitachi EX 210 LC Super Series Machinery information such as price list, technical specifications, video, and images. That all kinds of information are trustworthy and reliable, So you can trust it, my friends, because we always care about our site readers. Ok friends let’s move on our main topic.
Also Read:
TATA Hitachi EX 210 LC Super Series Machinery Quick Facts
- Model Code: EX 210 LC
- Engine Power: 133 PS @2000 rpm
- Operating Weight: 20,600 kg
- Bucket Capacity: 0.8 – 1.5 m3
TATA Hitachi EX 210 LC Super Series Machinery Operating Video
TATA Hitachi EX 210 LC Super Series Machinery Price
The TATA Hitachi EX 210 LC Super Series Machinery price Starts at 20 Lakh
TATA Hitachi EX 210 LC Super Series Machinery Specifications
| ENGINE | |
| Model | Cummins 6BT5-9C |
| Type | 6 cylinder in-line water cooled |
| Rated fly wheel power | 133 ps @ 2000 rpm |
| Maximum torque | 54.8 kgf @ 1300 rpm |
| Batteries | 2 X 12 V |
| HYDRAULIC SYSTEM | |
| Main pumps | 2 variable displacement axial piston pumps |
| Max. Oil Flow | 2 x 221 Lpm |
| Pilot pump | 1 gear pump |
| Max. Oil Flow | 20 lpm |
| SUPER STRUCTURE | |
| Swing speed | 13.7 rpm |
| UNDERCARRIAGE | |
| Travel speeds | 0-4.2 Kmph |
| Maximum traction force | 15,200 kgf |
| Gradibility | 35deg (70 % continuous) |
| No. of upper rollers | 2 |
| No. of lower rollers | 8 |
| No. of track shoes | 52 |
| Shoe width | 600 mm |
| SERVICE REFILL CAPACITIES | |
| Hydraulic Tank | 129.0 L |
| Hydraulic system | 220.0 L |
| Fuel tank | 310.0 L |
| Engine coolant | 35.0 L |
| Engine oil (Sump) | 14.0 L |
| Swing device | 7.5 L |
| Travel device (each side) | 5.5 L |
| RELIEF VALVE SETTINGS | |
| Implement circuit | 285 kgf /cm2 |
| Swing circuit | 260 kgf /cm2 |
| Travel circuit | 350 kgf /cm2 |
| Pilot circuit | 40 kgf /cm2 |
| WEIGHTS AND GROUND PRESSURE | ||
| Machine | Operating weight | Ground pressure |
| Backhoe | 20,600 kg | 0.44 kgf / cm2 |
| BUCKETS | |||
| Capacity | Width Without side cutter | Weight (approx.) | Tooth points |
| 0.80 m3 | 997 mm | 902 kg | 4 |
| 0.91 m3 | 1150 mm | 741 kg | 5 |
| 1.20 m3 | 1450mm | 690 kg | – |
| 1.5 m3 | 1780 mm | 567 kg | – |
| DIGGING FORCES | |||
| BACKHOE | |||
| Bucket digging forces | 11000 kgf | ||
| Arm Length | 1.90 m | 2.22 m | 2.90 m |
| Arm digging force | 12500 kgf | 11300 kgf | 8800 kgf |
| WORKING RANGES | |||
| ARM LENGTH | 1900 | 2220 | 2900 |
| Maximum digging reach | 9110 | 9250 | 9910 |
| Maximum digging reach (On ground) | 8920 | 9060 | 9740 |
| Maximum digging depth | 5580 | 5970 | 6600 |
| Maximum digging depth (8′ level) | 5340 | 5670 | 6420 |
| Maximum cutting height | 9340 | 8990 | 9400 |
| Maximum dumping height | 6480 | 6230 | 6610 |
| Maximum swing radius | 4010 | 3720 | 3660 |
| Minimum vertical wall depth | 4950 | 5050 | 5980 |
Final Words
That was all about the TATA Hitachi EX 210 Lc Construction machinery. I hope this article, helpful to you, but if you have any questions about this article, then please comment below in the comment box my friends, we will solve your problem as soon as. And Stay tuned with me for more stuff like this friend, Thanks for visiting our site. And Keep Visiting our site friends.
