Kioti NX 5010 Series Tractors Specs, Price, Features, Images
Kioti NX Series 5010 Tractor models featured with 3 Range Hydrostatic Transmission, 24×24 Manual Transmission, CRDI diesel with Daedong ECO Technology, Independent PTO with Auto and Manual Selection, PTO Cruise Control, True Speed Cruise Control, Rear Differential Lock, Torque Compensation, and Open Station (ROPS).
Are you planning to buy Kioti NX 5010 Tractors? And do you know about the Kioti NX 5010 Tractors Information, Price List, Specifications, Key features? So Don’t worry my friends here in this article.
I am going to introduce the Kioti NX series 5010 Model tractors information such as price list, engine details, hydraulics performance, mileage, power take-off, transmission system, tire size, fuel system etc.
That all kinds of information are true and genuine, you can trust on it. And that is very helpful to you for buy or sell this model tractor. Ok so let’s start it step by step.
You may also see here:
- Swaraj 855 FE Tractor
- Swaraj Tractors Price List
- Mini Tractors Price List in India
- Sonalika All Model Tractors Price
Now here you can get the Kioti NX 5010 series of all tractors information in detail.
Kioti NX5010 Tractor
Kioti NX5010 Tractor Key Features
- Engine Gross Horsepower: 50 hp
- Transmission Type: 24×24 Manual
- PTO Type: Independent
- Shuttle: Synchronized
- PTO Horsepower: 41.8 hp
- Lifting Capacity: 1441 kg
Kioti NX5010 Tractor Price
The Kioti NX5010 Tractor price will be $30,500.
Kioti NX5010 Tractor Specifications
| ENGINE | |
| Engine Model | 3F183T |
| Engine Gross Power | 50 hp (37.3 kW) |
| Rated Speed | 2,600 rpm |
| No. of Cylinders | 3 |
| Fuel Type | Diesel |
| Aspiration | Turbo Charged |
| Displacement | 111.4 cu. in. (1,826 cc) |
| Fuel Tank Capacity | 14.8 gal. (56 L) |
| TRANSMISSION | |
| Transmission Type | Manual |
| Shuttle | Synchronized |
| Main Gear | Synchronized |
| No. of Travel Speeds – Forward / Reverse | 24 x 24 |
| Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed | 0.11 mph (0.17 km/h) |
| Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed | 15.71 mph (25.28 km/h) |
| Brakes | Wet Multi Disc |
| Clutch | Dry Single Plate |
| HYDRAULICS | |
| Pump | Gear |
| Pump Capacity (Max. Flow Rate) | 16.5 gpm (62.4 L/min) |
| POWER TAKE OFF | |
| PTO Type Trans | Independent |
| PTO Power | 41.8 hp (31.2 kW) |
| Rear PTO Speeds(1st) | 540 rpm |
| Mid PTO Speeds | 2,000 rpm (Optional) |
| DIMENSIONS W/AG TIRE | |
| Length w/ 3-point hitch | 139.6 in. (3,547 mm) |
| Width | 65.6 in. (1,665 mm) |
| Height from Top of ROPS Cab | 103.1 in. (2,618 mm) |
| From Top of the Highest Point | NA |
| Wheelbase | 75.6 in. (1,920 mm) |
| Ground Clearance | 13.7 in. (350 mm) |
| Front Tread Ag Tires – Min | 55.2 in. (1,352 mm) |
| Rear Tread Ag Tires – Min | 52.1 in. (1,324 mm) |
| Turning Radius w/ Brake | 9.81 ft. (2.99 m) |
| Weight w/ Ag Tires w/ Cab | 4,011 lbs. (1,819.4 kg) |
| 3-POINT HITCH | |
| Standard Category | Category I |
| Lift Capacity, 24″ aft of hitch, lb(kg) | 3,177 lbs. (1,441 kg) |
| Control Type | Position with Draft Control |
| TIRE SIZE | |
| Agricultural | |
| Front | 8-16 |
| Rear | 13.6-24 |
| Truf | |
| Front | 29-12.5-15 |
| Rear | 21.5L-16.1 |
| Industrial | |
| Front | 10-16.5 |
| Rear | 14.9-24 |
Kioti NX5010 HST Tractor
Kioti NX5010 HST Tractor Key Features
- Engine Gross Horsepower: 50 hp
- Transmission Type: 3 Range Hydrostatic
- PTO Type: Independent
- True Speed Cruise Control
- PTO Horsepower: 38.9 hp hp
- Lifting Capacity: 1441 kg
Also Check:
- Kioti CK4010SE
- Kioti CK3510SE HC
- Kioti CK3510SE
- Kioti CS Series Tractors
- Kioti NX 4510
- Kioti CK10 Series Tractors
- Kioti DK 10 Series Tractors
- Kioti NX Series 5010 Tractors
- Kioti NX Series Tractors
Kioti NX5010 HST Tractor Price
The Kioti NX5010 HST Tractor price is $31,308.
Kioti NX5010 HST Tractor Specifications
| ENGINE | |
| Engine Model | 3F183T |
| Engine Gross Power | 50 hp (37.3 kW) |
| Rated Speed | 2,600 rpm |
| No. of Cylinders | 3 |
| Fuel Type | Diesel |
| Aspiration | Turbo Charged |
| Displacement | 111.4 cu. in. (1,826 cc) |
| Fuel Tank Capacity | 14.8 gal. (56 L) |
| TRANSMISSION | |
| Transmission Type | Hydrostatic |
| Shuttle | NA |
| Main Gear | NA |
| No. of Travel Speeds – Forward / Reverse | 3 Range |
| Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed | 0 mph (0 km/h) |
| Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed | 16.52 mph (26.59 km/h) |
| Brakes | Wet Multi Disc |
| Clutch | NA |
| HYDRAULICS | |
| Pump | Gear |
| Pump Capacity (Max. Flow Rate) | 17.9 gpm (67.6 L/min) |
| POWER TAKE OFF | |
| PTO Type Trans | Independent |
| PTO Power | 38.9 hp (29 kW) |
| Rear PTO Speeds(1st) | 540 rpm |
| Mid PTO Speeds | 2,000 rpm (Optional) |
| DIMENSIONS W/AG TIRE | |
| Length w/ 3-point hitch | 139.6 in. (3,547 mm) |
| Width | 65.6 in. (1,665 mm) |
| Height from Top of ROPS Cab | 103.1 in. (2,618 mm) |
| From Top of the Highest Point | NA |
| Wheelbase | 75.6 in. (1,920 mm) |
| Ground Clearance | 13.7 in. (350 mm) |
| Front Tread Ag Tires – Min | 55.2 in. (1,352 mm) |
| Rear Tread Ag Tires – Min | 52.1 in. (1,324 mm) |
| Turning Radius w/ Brake | 9.81 ft. (2.99 m) |
| Weight w/ Ag Tires w/ Cab | 4,000 lbs. (1,814.4 kg) |
| 3-POINT HITCH | |
| Standard Category | Category I |
| Lift Capacity, 24″ aft of hitch, lb(kg) | 3,177 lbs. (1,441 kg) |
| Control Type | Position with Draft Control |
| TIRE SIZE | |
| Agricultural | |
| Front | 8-16 |
| Rear | 13.6-24 |
| Truf | |
| Front | 29-12.5-15 |
| Rear | 21.5L-16.1 |
| Industrial | |
| Front | 10-16.5 |
| Rear | 14.9-24 |
Kioti NX5010 CAB Tractor
Kioti NX5010 CAB Tractor Key Features
- Engine Gross Horsepower: 50 hp
- Transmission Type: 24×24 Manual
- PTO Type: Independent
- True Speed Cruise Control
- PTO Horsepower: 41.8 hp
- Lifting Capacity: 1441 kg
Kioti NX5010 CAB Tractor Price
The Kioti NX5010 CAB Tractor price will be $31,600.
Kioti NX5010 CAB Tractor Specifications
| ENGINE | |
| Engine Model | 3F183T |
| Engine Gross Power | 50 hp (37.3 kW) |
| Rated Speed | 2,600 rpm |
| No. of Cylinders | 3 |
| Fuel Type | Diesel |
| Aspiration | Turbo Charged |
| Displacement | 111.4 cu. in. (1,826 cc) |
| Fuel Tank Capacity | 14.8 gal. (56 L) |
| TRANSMISSION | |
| Transmission Type | Manual |
| Shuttle | Synchronized |
| Main Gear | Synchronized |
| No. of Travel Speeds – Forward / Reverse | 24 x 24 |
| Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed | 0.11 mph (0.17 km/h) |
| Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed | 15.71 mph (25.28 km/h) |
| Brakes | Wet Multi Disc |
| Clutch | Dry Single Plate |
| HYDRAULICS | |
| Pump | Gear |
| Pump Capacity (Max. Flow Rate) | 16.5 gpm (62.4 L/min) |
| POWER TAKE OFF | |
| PTO Type Trans | Independent |
| PTO Power | 41.8 hp (31.2 kW) |
| Rear PTO Speeds(1st) | 540 rpm |
| Mid PTO Speeds | 2,000 rpm (Optional) |
| DIMENSIONS W/AG TIRE | |
| Length w/ 3-point hitch | 139.6 in. (3,547 mm) |
| Width | 65.6 in. (1,665 mm) |
| Height from Top of ROPS Cab | 94.1 in. (2,390 mm) |
| From Top of the Highest Point | NA |
| Wheelbase | 75.6 in. (1,920 mm) |
| Ground Clearance | 13.7 in. (350 mm) |
| Front Tread Ag Tires – Min | 55.2 in. (1,352 mm) |
| Rear Tread Ag Tires – Min | 52.1 in. (1,324 mm) |
| Turning Radius w/ Brake | 9.81 ft. (2.99 m) |
| Weight w/ Ag Tires w/ Cab | 4,324 lbs. (1,961.4 kg) |
| 3-POINT HITCH | |
| Standard Category | Category I |
| Lift Capacity, 24″ aft of hitch, lb(kg) | 3,177 lbs. (1,441 kg) |
| Control Type | Position with Draft Control |
| TIRE SIZE | |
| Agricultural | |
| Front | 8-16 |
| Rear | 13.6-24 |
| Truf | |
| Front | 29-12.5-15 |
| Rear | 21.5L-16.1 |
| Industrial | |
| Front | 10-16.5 |
| Rear | 14.9-24 |
Kioti NX5010 HST CAB Tractor
Kioti NX5010 HST CAB Tractor Key Features
- Engine Gross Horsepower: 50 hp
- Transmission Type: 3 Range Hydrostatic
- PTO Type: Independent
- True Speed Cruise Control
- PTO Horsepower: 38.9 hp hp
- Lifting Capacity: 1441 kg
Kioti NX5010 HST CAB Tractor Price
The Kioti NX5010 HST CAB Tractor price will be $44,452.
Kioti NX5010 HST CAB Tractor Specifications
| ENGINE | |
| Engine Model | 3F183T |
| Engine Gross Power | 50 hp (37.3 kW) |
| Rated Speed | 2,600 rpm |
| No. of Cylinders | 3 |
| Fuel Type | Diesel |
| Aspiration | Turbo Charged |
| Displacement | 111.4 cu. in. (1,826 cc) |
| Fuel Tank Capacity | 14.8 gal. (56 L) |
| TRANSMISSION | |
| Transmission Type | Hydrostatic |
| Shuttle | NA |
| Main Gear | NA |
| No. of Travel Speeds – Forward / Reverse | 3 Range |
| Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed | 0 mph (0 km/h) |
| Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed | 16.52 mph (26.59 km/h) |
| Brakes | Wet Multi Disc |
| Clutch | NA |
| HYDRAULICS | |
| Pump | Gear |
| Pump Capacity (Max. Flow Rate) | 17.9 gpm (67.6 L/min) |
| POWER TAKE OFF | |
| PTO Type Trans | Independent |
| PTO Power | 38.9 hp (29 kW) |
| Rear PTO Speeds(1st) | 540 rpm |
| Mid PTO Speeds | 2,000 rpm (Optional) |
| DIMENSIONS W/AG TIRE | |
| Length w/ 3-point hitch | 139.6 in. (3,547 mm) |
| Width | 65.6 in. (1,665 mm) |
| Height from Top of ROPS Cab | 94.1 in. (2,390 mm) |
| From Top of the Highest Point | NA |
| Wheelbase | 75.6 in. (1,920 mm) |
| Ground Clearance | 13.7 in. (350 mm) |
| Front Tread Ag Tires – Min | 55.2 in. (1,352 mm) |
| Rear Tread Ag Tires – Min | 52.1 in. (1,324 mm) |
| Turning Radius w/ Brake | 9.81 ft. (2.99 m) |
| Weight w/ Ag Tires w/ Cab | 4,315 lbs. (1,957.3 kg) |
| 3-POINT HITCH | |
| Standard Category | Category I |
| Lift Capacity, 24″ aft of hitch, lb(kg) | 3,177 lbs. (1,441 kg) |
| Control Type | Position with Draft Control |
| TIRE SIZE | |
| Agricultural | |
| Front | 8-16 |
| Rear | 13.6-24 |
| Truf | |
| Front | 29-12.5-15 |
| Rear | 21.5L-16.1 |
| Industrial | |
| Front | 10-16.5 |
| Rear | 14.9-24 |
Final Words
So these were the Kioti NX5010 Tractors features, I hope you enjoyed reading this article and the features of Kioti NX5010. If you want to share your thought on this Tractor then please share them to do so you can comment below. Thanks for reading and stay tuned for more stuff like this.
