CASE IH FARMALL A Series Tractors Specs Overview
Hello, Peoples!! Are you Searching CASE IH FARMALL A Series Tractors such as CASE FARMALL 110A, CASE FARMALL 120A, CASE FARMALL 125A and CASE FARMALL 140A Tractor information like price list, Key features, all parts technical specification and more.
Here in this article, I am going to introduce that all kinds of information which you are finding. I hope it is helpful to you my friends. You can check below each only tractor information in detail so let’s see.
The Case IH utility Farmall A series tractors provide excellent value for your operations. Economical yet featuring durable, robust, efficient engines, transmissions, and a comfortable drivers area. Horsepower Range: 53 Hp – 70 Hp (Power Take Off: 45-62)
You Can Find Here:
- Eicher Tractors information
- Eicher Tractors All Model Price List
- Kubota Tractor Price List
- KUBOTA MINI TRACTORS PRICE LIST
- Mahindra Tractors Price List
CASE IH FARMALL 110 A Tractor
CASE IH FARMALL 110 A Tractor Price
The Cash IH Farmall 110 A Tractor price is USD $65,000
CASE IH FARMALL 110 A Tractor Key Features
- Engine Type: 4 Cylinders, Case IH FPT / NEF
- PTO Power: 95hp
- Horsepower: 110hp
- Max Torque ([email protected] rpm): 510
- Lifting capacity: 2410 kg
CASE IH FARMALL 110 A Tractor Specifications
| ENGINE | |
| Engine type | 4 cylinder |
| Make / Model | Case IH FPT / NEF |
| Displacement (L) | 4,5 |
| Aspiration | Turbo / intercooled |
| Rated Power (kW/hp) | 82 / 110 |
| PTO Power (kW/hp) | 71 / 95 |
| Max Torque ([email protected] rpm) | 510 |
| Emissions certification | Tier 3 |
| TRANSMISSION | |
| 8 x 8 Synchroshuttle | Standard |
| 8 x 8 Hydraulic Powershuttle | Optional |
| 16 x 8 Hydraulic Powershuttle & Hi-Lo | Optional |
| Creeper (option available on all transmissions) | Optional |
| FORWARD SPEED | |
| 30 kph version (18.4R38) | 31,7 kph |
| 40 kph version (18.4R38) | 40,5 kph |
| PTO (FULLY INDEPENDENT WET CLUTCH) | |
| Speed Std/Opt | 540/540-1000 |
| 3 point hitch | – |
| Category | II |
| Draft sensing | Top link |
| Rear Hydraulic Power Lift | Standard |
| Lift capacity (kg) | 2410 |
| Option with 1 add aux ram lift capacity (kg) | 3639 |
| Option with 2 add aux rams lift capacity (kg) | 4647 |
| HYDRAULICS | |
| Implement pump flow (L/min) | 49 |
| Implement “Hi-Flow” pump (L/min) | 83 |
| Steering pump fl ow (L/min) | 34 |
| AXLES | |
| Front 2WD adjustable tread width (mm) | 1422-2032 |
| Front 4WD adjustable tread width (mm) | 1626-2032 |
| Flange axle: Rear adjustable tread width (mm) | 1626-2032 |
| Optional bar axle: | |
| Rear adjustable tread width (mm) | 1575-2337 |
| Front axle turn angle (2WD / 4WD) (°) | 55 |
| WEIGHT | |
| Minimum shipping weight: 2WD ROPS / 4WD ROPS (kg) | 3413 / 3678 |
| 2WD cab / 4WD cab (kg) | 3588 / 4013 |
| DIMENSIONS* | |
| Wheelbase: 2WD / 4WD (mm) | 2571 / 2520 |
| Overall length (mm) | 4216 |
| 2WD / 4WD (mm) | 4115 / 4216 |
| Height, top of ROPS (mm) | 2959 |
| Height, top of cab (mm) | 2816 |
| Height, top of exhaust (mm) | 2959 |
| KEY CONFIGURATIONS | |
| 2WD ROPS | Optional |
| 4WD ROPS | Standard |
| 2WD cab | Optional |
| 4WD cab | Optional |
CASE IH FARMALL 120 A Tractor
CASE IH FARMALL 120A Tractor Price
The Cash IH Farmall 120 A Tractor price is USD $72,500
CASE IH FARMALL 120A Tractor Key Features
- Engine Type: 4 Cylinders, Case IH FPT / NEF
- PTO Power: 99hp
- Horsepower: 118hp
- Max Torque ([email protected] rpm): 515
- Lifting capacity: 2410 kg
CASE IH FARMALL 120A Tractor Specifications
| ENGINE | |
| Engine type | 4 cylinder |
| Make / Model | Case IH FPT / NEF |
| Displacement (L) | 4,5 |
| Aspiration | Turbo / intercooled |
| Rated Power (kW/hp) | 88 / 118 |
| PTO Power (kW/hp) | 74 / 99 |
| Max Torque ([email protected] rpm) | 515 |
| Emissions certification | Tier 3 |
| TRANSMISSION | |
| 8 x 8 Synchroshuttle | Standard |
| 8 x 8 Hydraulic Powershuttle | Optional |
| 16 x 8 Hydraulic Powershuttle & Hi-Lo | Optional |
| Creeper (option available on all transmissions) | Optional |
| FORWARD SPEED | |
| 30 kph version (18.4R38) | 31,7 kph |
| 40 kph version (18.4R38) | 40,5 kph |
| PTO (FULLY INDEPENDENT WET CLUTCH) | |
| Speed Std/Opt | 540/540-1000 |
| 3 point hitch | – |
| Category | II |
| Draft sensing | Top link |
| Rear Hydraulic Power Lift | Standard |
| Lift capacity (kg) | 2410 |
| Option with 1 add aux ram lift capacity (kg) | 3639 |
| Option with 2 add aux rams lift capacity (kg) | 4647 |
| HYDRAULICS | |
| Implement pump flow (L/min) | 49 |
| Implement “Hi-Flow” pump (L/min) | 83 |
| Steering pump fl ow (L/min) | 34 |
| AXLES | |
| Front 2WD adjustable tread width (mm) | 1422-2032 |
| Front 4WD adjustable tread width (mm) | 1626-2032 |
| Flange axle: Rear adjustable tread width (mm) | 1626-2032 |
| Optional bar axle: | |
| Rear adjustable tread width (mm) | 1575-2337 |
| Front axle turn angle (2WD / 4WD) (°) | 55 |
| WEIGHT | |
| Minimum shipping weight: 2WD ROPS / 4WD ROPS (kg) | 3413 / 3678 |
| 2WD cab / 4WD cab (kg) | 3588 / 4013 |
| DIMENSIONS* | |
| Wheelbase: 2WD / 4WD (mm) | 2571 / 2520 |
| Overall length (mm) | 4216 |
| 2WD / 4WD (mm) | 4115 / 4216 |
| Height, top of ROPS (mm) | 2959 |
| Height, top of cab (mm) | 2816 |
| Height, top of exhaust (mm) | 2959 |
| KEY CONFIGURATIONS | |
| 2WD ROPS | Optional |
| 4WD ROPS | Standard |
| 2WD cab | Optional |
| 4WD cab | Optional |
CASE IH FARMALL 125 A Tractor
CASE IH FARMALL 125 A Tractor Price
The Cash IH Farmall 125 A Tractor price is USD $54,000
CASE IH FARMALL 125 A Tractor Key Features
- Engine Type: 6 Cylinders, Case IH FPT / NEF
- PTO Power: 105hp
- Horsepower: 124hp
- Max Torque ([email protected] rpm): 555
- Lifting capacity: 2410 kg
CASE IH FARMALL 125 A Tractor Specifications
| ENGINE | |
| Engine type | 6 cylinder |
| Make / Model | Case IH FPT / NEF |
| Displacement (L) | 6,7 |
| Aspiration | Turbo / intercooled |
| Rated Power (kW/hp) | 93 / 124 |
| PTO Power (kW/hp) | 77 / 105 |
| Max Torque ([email protected] rpm) | 555 |
| Emissions certification | Tier 3 |
| TRANSMISSION | |
| 8 x 8 Synchroshuttle | Standard |
| 8 x 8 Hydraulic Powershuttle | Optional |
| 16 x 8 Hydraulic Powershuttle & Hi-Lo | Optional |
| Creeper (option available on all transmissions) | Optional |
| FORWARD SPEED | |
| 30 kph version (18.4R38) | 31,7 kph |
| 40 kph version (18.4R38) | 40,5 kph |
| PTO (FULLY INDEPENDENT WET CLUTCH) | |
| Speed Std/Opt | 540-1000/– |
| 3 point hitch | – |
| Category | II |
| Draft sensing | Top link |
| Rear Hydraulic Power Lift | Standard |
| Lift capacity (kg) | 2410 |
| Option with 1 add aux ram lift capacity (kg) | 3639 |
| Option with 2 add aux rams lift capacity (kg) | 4647 |
| HYDRAULICS | |
| Implement pump flow (L/min) | 49 |
| Implement “Hi-Flow” pump (L/min) | 83 |
| Steering pump fl ow (L/min) | 34 |
| AXLES | |
| Front 2WD adjustable tread width (mm) | 1422-2032 |
| Front 4WD adjustable tread width (mm) | 1626-2032 |
| Flange axle: Rear adjustable tread width (mm) | 1626-2032 |
| Optional bar axle: | |
| Rear adjustable tread width (mm) | 1575-2337 |
| Front axle turn angle (2WD / 4WD) (°) | 55 |
| WEIGHT | |
| Minimum shipping weight: 2WD ROPS / 4WD ROPS (kg) | 3613 / 3878 |
| 2WD cab / 4WD cab (kg) | 3788 / 4213 |
| DIMENSIONS* | |
| Wheelbase: 2WD / 4WD (mm) | 2631 / 2627 |
| Overall length (mm) | 4216 |
| 2WD / 4WD (mm) | 4191 / 4293 |
| Height, top of ROPS (mm) | 2959 |
| Height, top of cab (mm) | 2816 |
| Height, top of exhaust (mm) | 2959 |
| KEY CONFIGURATIONS | |
| 2WD ROPS | Optional |
| 4WD ROPS | Standard |
| 2WD cab | Optional |
| 4WD cab | Optional |
CASE IH FARMALL 140 A Tractor
CASE IH FARMALL 140 A Tractor Price
The Cash IH Farmall 140 A Tractor price is USD $80,900
CASE IH FARMALL 140 A Tractor Key Features
- Engine Type: 6 Cylinders, Case IH FPT / NEF
- PTO Power: 118hp
- Horsepower: 139hp
- Max Torque ([email protected] rpm): 625
- Lifting capacity: 2410 kg
CASE IH FARMALL 140 A Tractor Specifications
| ENGINE | |
| Engine type | 6 cylinder |
| Make / Model | Case IH FPT / NEF |
| Displacement (L) | 6,7 |
| Aspiration | Turbo / intercooled |
| Rated Power (kW/hp) | 104 / 139 |
| PTO Power (kW/hp) | 88 / 118 |
| Max Torque ([email protected] rpm) | 625 |
| Emissions certification | Tier 3 |
| TRANSMISSION | |
| 8 x 8 Synchroshuttle | Standard |
| 8 x 8 Hydraulic Powershuttle | Optional |
| 16 x 8 Hydraulic Powershuttle & Hi-Lo | Optional |
| Creeper (option available on all transmissions) | Optional |
| FORWARD SPEED | |
| 30 kph version (18.4R38) | 31,7 kph |
| 40 kph version (18.4R38) | 40,5 kph |
| PTO (FULLY INDEPENDENT WET CLUTCH) | |
| Speed Std/Opt | 540-1000/– |
| 3 point hitch | – |
| Category | II |
| Draft sensing | Top link |
| Rear Hydraulic Power Lift | Standard |
| Lift capacity (kg) | 2410 |
| Option with 1 add aux ram lift capacity (kg) | 3639 |
| Option with 2 add aux rams lift capacity (kg) | 4647 |
| HYDRAULICS | |
| Implement pump flow (L/min) | 49 |
| Implement “Hi-Flow” pump (L/min) | 83 |
| Steering pump fl ow (L/min) | 34 |
| AXLES | |
| Front 2WD adjustable tread width (mm) | 1422-2032 |
| Front 4WD adjustable tread width (mm) | 1626-2032 |
| Flange axle: Rear adjustable tread width (mm) | 1626-2032 |
| Optional bar axle: | |
| Rear adjustable tread width (mm) | 1575-2337 |
| Front axle turn angle (2WD / 4WD) (°) | 55 |
| WEIGHT | |
| Minimum shipping weight: 2WD ROPS / 4WD ROPS (kg) | 3613 / 3878 |
| 2WD cab / 4WD cab (kg) | 3788 / 4213 |
| DIMENSIONS* | |
| Wheelbase: 2WD / 4WD (mm) | 2631 / 2627 |
| Overall length (mm) | 4216 |
| 2WD / 4WD (mm) | 4191 / 4293 |
| Height, top of ROPS (mm) | 2959 |
| Height, top of cab (mm) | 2816 |
| Height, top of exhaust (mm) | 2959 |
| KEY CONFIGURATIONS | |
| 2WD ROPS | Optional |
| 4WD ROPS | Standard |
| 2WD cab | Optional |
| 4WD cab | Optional |
That was all about the CASE IH FARMALL A Series Tractors, hope you like this post, but if you have any query regarding this post, then please friends comment in the comment section, we will solve your doubt as soon, Thanks for visiting our site and stay with me for new other tractor information.
