Case IH Magnum Series Tractors Information With Price List

Hello, Farmer! Here in this article, I am going to Introduce the CASE IH Magnum Series Tractors such as Magnum 180, Magnum 200, Magnum 220, Magnum 240, Magnum 250, Magnum 280, Magnum 310, Magnum 340 and Magnum 380 tractor model Information in details. Here you can get this types of information about this tractor like that price list, key features, Technical specification, images and more.

I hope That all kinds of information very useful to you for buy or sell this model tractors, because that all kinds of information are trustworthy and reliable. Ok Friends, Let’s go for that.

Check Here:

Contents

CASE IH Magnum 180 Tractor

CASE IH Magnum 180 Tractor



CASE IH Magnum 180 Tractor Price

The Case IH Magnum 180 Tractor Price  $188,095



CASE IH Magnum 180 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP : 200
  • PTO HP: 155
  • Cylinder: 6
  • Standard Hitch Lift Capacity: 6170 kg without Quick Coupler
  • Fuel Tank Capacity: 600 L

CASE IH Magnum 180 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2,100 RPM (Magnum 180–240) ISO/ECE R120 (CV) 180
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 200
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 225
PTO HP @ rated 2,100 RPM (Magnum 180–240) per SAE 155
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /6.7L
Engine Aspiration Turbocharger Wastegate
Engine Compression Brake NA
ElECTRICAL
Alternator (Amp) 200
Battery capacity 12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) NA
Powershift: 19 Speed (Economy) –25 MPH (40 kph) Standard
Powershift: 19 Speed–30 MPH (50 kph) Optional
CVT Transmission–25 mph (40 kph) Optional
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 540/1,000 RPM 1 3/8 in. (35 mm) shafts /NA
AXLES
Rear Axle Diameter – Standard/Optional 4 in.(100 mm)/NA
Rear Axle Length – Standard/Optiona 119 in. (3020 mm)/112 in. (2489 mm)
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 axles
Wheelbase – Powershift 118 in. (3000 mm)
Wheelbase – CVT 118 in. (3000 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 3, 4 or 5 Electro-hydraulic
Main Implement Pump Flow FPS = 41 gpm (156 L/min.)/CVT = 43 gpm (162 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat III/IIIN/NA
Standard Hitch Lift Capacity 13,600 lbs. (6170 kg) without Quick Coupler; 13,000 lbs. (5900 kg) with Quick Coupler
Optional Front 3-pt Hitch Lift Capacity NA
Front Hitch PTO Speed and Shaft Size NA
CAPACITIES
Fuel Tank 160 gal. (600L)
Diesel Exhaust Fluid (DEF) Tank 17.5 gal. (66L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.) /67 dBa
WEIGHT
Average Standard Weight 21,500 lbs. (9750 kg)




CASE IH Magnum 200 Tractor



CASE IH Magnum 200 Tractor



CASE IH Magnum 200 Tractor Price

The Case IH Magnum 200 Tractor Price  $197,469 (Powershift ) |  $207,228 (CVT )



CASE IH Magnum 200 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP: 220
  • PTO HP: 180
  • Cylinder: 6
  • Standard Hitch Lift Capacity: 6170 kg without Quick Coupler
  • Fuel Tank Capacity: 600 L

CASE IH Magnum 200 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2,100 RPM (Magnum 180–240) ISO/ECE R120 (CV) 200
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 220
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 245
PTO HP @ rated 2,100 RPM (Magnum 180–240) per SAE 170
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /6.7L
Engine Aspiration Turbocharger Wastegate
Engine Compression Brake NA
ElECTRICAL
Alternator (Amp) 200
Battery capacity 12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) NA
Powershift: 19 Speed (Economy) –25 MPH (40 kph) Standard
Powershift: 19 Speed–30 MPH (50 kph) Optional
CVT Transmission–25 mph (40 kph) Optional
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 540/1,000 RPM 1 3/8 in. (35 mm) shafts /NA
AXLES
Rear Axle Diameter – Standard/Optional 4 in.(100 mm)/NA
Rear Axle Length – Standard/Optiona 119 in. (3020 mm)/112 in. (2489 mm)
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 axles
Wheelbase – Powershift 118 in. (3000 mm)
Wheelbase – CVT 118 in. (3000 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 3, 4 or 5 Electro-hydraulic
Main Implement Pump Flow FPS = 41 gpm (156 L/min.)/CVT = 43 gpm (162 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat III/IIIN/NA
Standard Hitch Lift Capacity 13,600 lbs. (6170 kg) without Quick Coupler; 13,000 lbs. (5900 kg) with Quick Coupler
Optional Front 3-pt Hitch Lift Capacity NA
Front Hitch PTO Speed and Shaft Size NA
CAPACITIES
Fuel Tank 160 gal. (600L)
Diesel Exhaust Fluid (DEF) Tank 17.5 gal. (66L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.) /67 dBa
WEIGHT
Average Standard Weight 21,500 lbs. (9750 kg)




CASE IH Magnum 220 Tractor



 CASE IH Magnum 220 Tractor



CASE IH Magnum 220 Tractor Price

The Case IH Magnum 220 Tractor Price $206,347 (Powershift) | $216,106 (CVT )



CASE IH Magnum 220 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP: 240
  • PTO HP: 185
  • Cylinder: 6
  • Standard Hitch Lift Capacity: 6170 kg without Quick Coupler
  • Fuel Tank Capacity: 600 L

CASE IH Magnum 220 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2,100 RPM (Magnum 180–240) ISO/ECE R120 (CV) 220
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 240
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 260
PTO HP @ rated 2,100 RPM (Magnum 180–240) per SAE 185
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /6.7L
Engine Aspiration Turbocharger Wastegate
Engine Compression Brake NA
ElECTRICAL
Alternator (Amp) 200
Battery capacity 12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) NA
Powershift: 19 Speed (Economy) –25 MPH (40 kph) Standard
Powershift: 19 Speed–30 MPH (50 kph) Optional
CVT Transmission–25 mph (40 kph) Optional
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 540/1,000 RPM 1 3/8 in. (35 mm) shafts /NA
AXLES
Rear Axle Diameter – Standard/Optional 4 in.(100 mm)/NA
Rear Axle Length – Standard/Optiona 119 in. (3020 mm)/112 in. (2489 mm)
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 axles
Wheelbase – Powershift 118 in. (3000 mm)
Wheelbase – CVT 118 in. (3000 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 3, 4 or 5 Electro-hydraulic
Main Implement Pump Flow FPS = 41 gpm (156 L/min.)/CVT = 43 gpm (162 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat III/IIIN/NA
Standard Hitch Lift Capacity 13,600 lbs. (6170 kg) without Quick Coupler; 13,000 lbs. (5900 kg) with Quick Coupler
Optional Front 3-pt Hitch Lift Capacity NA
Front Hitch PTO Speed and Shaft Size NA
CAPACITIES
Fuel Tank 160 gal. (600L)
Diesel Exhaust Fluid (DEF) Tank 17.5 gal. (66L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.) /67 dBa
WEIGHT
Average Standard Weight 21,500 lbs. (9750 kg)




CASE IH Magnum 240 Tractor

 CASE IH Magnum 240 Tractor



CASE IH Magnum 240 Tractor Price

The Case IH Magnum 240 Tractor Price $225,400(CVT).



CASE IH Magnum 240 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP: 260
  • PTO HP: 205
  • Cylinder: 6
  • Standard Hitch Lift Capacity: 6170 kg without Quick Coupler
  • Fuel Tank Capacity: 600 L

CASE IH Magnum 240 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2,100 RPM (Magnum 180–240) ISO/ECE R120 (CV) 240
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 260
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 270
PTO HP @ rated 2,100 RPM (Magnum 180–240) per SAE 205
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /6.7L
Engine Aspiration Turbocharger Wastegate
Engine Compression Brake NA
ElECTRICAL
Alternator (Amp) 200
Battery capacity 12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) NA
Powershift: 19 Speed (Economy) –25 MPH (40 kph) NA
Powershift: 19 Speed–30 MPH (50 kph) NA
CVT Transmission–25 mph (40 kph) Optional
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 540/1,000 RPM 1 3/8 in. (35 mm) shafts /NA
AXLES
Rear Axle Diameter – Standard/Optional 4 in.(100 mm)/NA
Rear Axle Length – Standard/Optiona 119 in. (3020 mm)/112 in. (2489 mm)
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 axles
Wheelbase – Powershift 118 in. (3000 mm)
Wheelbase – CVT 118 in. (3000 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 3, 4 or 5 Electro-hydraulic
Main Implement Pump Flow FPS = 41 gpm (156 L/min.)/CVT = 43 gpm (162 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat III/IIIN/NA
Standard Hitch Lift Capacity 13,600 lbs. (6170 kg) without Quick Coupler; 13,000 lbs. (5900 kg) with Quick Coupler
Optional Front 3-pt Hitch Lift Capacity NA
Front Hitch PTO Speed and Shaft Size NA
CAPACITIES
Fuel Tank 160 gal. (600L)
Diesel Exhaust Fluid (DEF) Tank 17.5 gal. (66L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.) /67 dBa
WEIGHT
Average Standard Weight 21,500 lbs. (9750 kg)




CASE IH Magnum 250 Tractor

CASE IH Magnum 250 Tractor



CASE IH Magnum 250 Tractor Price

The Case IH Magnum 250 Tractor Price $234,323 (PowerShift) | $247,665 CVT



CASE IH Magnum 250 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP: 285
  • PTO HP: 205
  • Cylinder: 6
  • Standard Hitch Lift Capacity: 5850 kg
  • Fuel Tank Capacity: Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)

CASE IH Magnum 250 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2000 RPM 250
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 285
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 320
PTO HP @ rated 2000 RPM (Magnum 250 – 380) per SAE 205
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /8.7L
Engine Aspiration Turbocharger Wastegate
Engine Compression Brake Optional
ElECTRICAL
Alternator (Amp) 200
Battery capacity 2-12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) Optional
Powershift: 19 Speed (Economy) –25 MPH (40 kph) Standard
Powershift: 19 Speed–30 MPH (50 kph) Optional
CVT Transmission–25 mph (40 kph) Optional
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 1,000 RPM 1 3/4 in. (44.5 mm) shafts / 540/1,000 RPM 1 3/8 in. (35 mm) shafts
AXLES
Rear Axle Diameter – Standard/Optional 4 in.(100 mm)/4.5 in. (115 mm)
Rear Axle Length – Standard 120 in. (3050 mm)/NA
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 and Class 5 axles
Wheelbase – Powershift 120 in. (3050 mm)
Wheelbase – CVT 122 in. (3100 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 4 Electro-hydraulic /5 or 6 Electro-hydraulic
Main Implement Pump Flow 44 gpm (166 L/min.) / 59 gpm (225 L/min.) or 75 gpm (282 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat III/IIIN/NA
Standard Hitch Lift Capacity 12,900 lbs (5850 kg)
Optional Front 3-pt Hitch Lift Capacity 9,426 lbs. (4275 kg)
Front Hitch PTO Speed and Shaft Size 1,000 RPM 1 3/8 in. (35 mm) shaft 21 spline
CAPACITIES
Fuel Tank Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)
Diesel Exhaust Fluid (DEF) Tank 26 gal. (99L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.)/67 dBa
WEIGHT
Average Standard Weight 28,600 lbs. (12973 kg)




CASE IH Magnum 280 Tractor

 CASE IH Magnum 280 Tractor



CASE IH Magnum 280 Tractor Price

The Case IH Magnum 280 Tractor Price $251,024 (Power Shift) |  $264,366 (CVT).

 Find Here:

CASE IH Magnum 280 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP: 315
  • PTO HP: 235
  • Standard Hitch Lift Capacity: 5850 kg
  • Cylinder: 6
  • Fuel Tank Capacity: Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)

CASE IH Magnum 280 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2000 RPM 280
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 315
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 350
PTO HP @ rated 2000 RPM (Magnum 250 – 380) per SAE 235
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /8.7L
Engine Aspiration Turbocharger eVGT
Engine Compression Brake Optional
ElECTRICAL
Alternator (Amp) 200
Battery capacity 2-12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) Optional
Powershift: 19 Speed (Economy) –25 MPH (40 kph) Standard
Powershift: 19 Speed–30 MPH (50 kph) Optional
CVT Transmission–25 mph (40 kph) Optional
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 1,000 RPM 1 3/4 in. (44.5 mm) shafts / 540/1,000 RPM 1 3/8 in. (35 mm) shafts
AXLES
Rear Axle Diameter – Standard/Optional 4 in.(100 mm)/4.5 in. (115 mm)
Rear Axle Length – Standard 120 in. (3050 mm)/NA
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 and Class 5 axles
Wheelbase – Powershift 120 in. (3050 mm)
Wheelbase – CVT 122 in. (3100 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 4 Electro-hydraulic /5 or 6 Electro-hydraulic
Main Implement Pump Flow 44 gpm (166 L/min.) / 59 gpm (225 L/min.) or 75 gpm (282 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat III/IIIN/Cat IV/III
Standard Hitch Lift Capacity 12,900 lbs (5850 kg)
Optional Front 3-pt Hitch Lift Capacity 9,426 lbs. (4275 kg)
Front Hitch PTO Speed and Shaft Size 1,000 RPM 1 3/8 in. (35 mm) shaft 21 spline
CAPACITIES
Fuel Tank Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)
Diesel Exhaust Fluid (DEF) Tank 26 gal. (99L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.)/67 dBa
WEIGHT
Average Standard Weight 28,600 lbs. (12973 kg)




CASE IH Magnum 310 Tractor

 CASE IH Magnum 310 Tractor



CASE IH Magnum 310 Tractor Price

The Case IH Magnum 310 Tractor Price $275,312 (PowerShift) | $288,654 CVT



CASE IH Magnum 310 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP: 345
  • PTO HP: 265
  • Standard Hitch Lift Capacity: 7210 kg
  • Cylinder: 6
  • Fuel Tank Capacity: Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)

CASE IH Magnum 310 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2000 RPM 310
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 345
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 380
PTO HP @ rated 2000 RPM (Magnum 250 – 380) per SAE 265
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /8.7L
Engine Aspiration Turbocharger eVGT
Engine Compression Brake Optional
ElECTRICAL
Alternator (Amp) 200
Battery capacity 2-12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) Optional
Powershift: 19 Speed (Economy) –25 MPH (40 kph) Standard
Powershift: 19 Speed–30 MPH (50 kph) Optional
CVT Transmission–25 mph (40 kph) Optional
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 1,000 RPM 1 3/4 in. (44.5 mm) shafts / 540/1,000 RPM 1 3/8 in. (35 mm) shafts
AXLES
Rear Axle Diameter – Standard/Optional 4.5 in.(115 mm)/NA
Rear Axle Length – Standard 120 in. (3050 mm)/NA
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 and Class 5 axles
Wheelbase – Powershift 120 in. (3050 mm)
Wheelbase – CVT 122 in. (3100 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 4 Electro-hydraulic /5 or 6 Electro-hydraulic
Main Implement Pump Flow 44 gpm (166 L/min.) / 59 gpm (225 L/min.) or 75 gpm (282 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat III/IIIN/Cat IV/III
Standard Hitch Lift Capacity 15,900 (7210 kg)
Optional Front 3-pt Hitch Lift Capacity 9,426 lbs. (4275 kg)
Front Hitch PTO Speed and Shaft Size 1,000 RPM 1 3/8 in. (35 mm) shaft 21 spline
CAPACITIES
Fuel Tank Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)
Diesel Exhaust Fluid (DEF) Tank 26 gal. (99L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.)/67 dBa
WEIGHT
Average Standard Weight 28,800 lbs. (13082 kg)




CASE IH Magnum 340 Tractor

 CASE IH Magnum 340 Tractor

CASE IH Magnum 340 Tractor Price

The Case IH Magnum 340 Tractor Price USD $193,500.



CASE IH Magnum 340 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP: 375
  • PTO HP: 290
  • Standard Hitch Lift Capacity: 7940 kg
  • Cylinder: 6
  • Fuel Tank Capacity: Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)

CASE IH Magnum 340 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2000 RPM 340
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 375
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 410
PTO HP @ rated 2000 RPM (Magnum 250 – 380) per SAE 290
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /8.7L
Engine Aspiration Turbocharger eVGT
Engine Compression Brake Optional
ElECTRICAL
Alternator (Amp) 200
Battery capacity 2-12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) Optional
Powershift: 19 Speed (Economy) –25 MPH (40 kph) Standard
Powershift: 19 Speed–30 MPH (50 kph) Optional
CVT Transmission–25 mph (40 kph) Optional
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 1,000 RPM 1 3/4 in. (44.5 mm) shafts / 540/1,000 RPM 1 3/8 in. (35 mm) shafts
AXLES
Rear Axle Diameter – Standard/Optional 4.5 in.(115 mm)/NA
Rear Axle Length – Standard 120 in. (3050 mm)/NA
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 and Class 5 axles
Wheelbase – Powershift 120 in. (3050 mm)
Wheelbase – CVT 122 in. (3100 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 4 Electro-hydraulic /5 or 6 Electro-hydraulic
Main Implement Pump Flow 44 gpm (166 L/min.) / 59 gpm (225 L/min.) or 75 gpm (282 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat IV/III/NA
Standard Hitch Lift Capacity 17,500 lbs (7940 kg)
Optional Front 3-pt Hitch Lift Capacity 9,426 lbs. (4275 kg)
Front Hitch PTO Speed and Shaft Size 1,000 RPM 1 3/8 in. (35 mm) shaft 21 spline
CAPACITIES
Fuel Tank Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)
Diesel Exhaust Fluid (DEF) Tank 26 gal. (99L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.)/67 dBa
WEIGHT
Average Standard Weight 29,600 lbs. (13458 kg)




CASE IH Magnum 380 Tractor

 CASE IH Magnum 380 Tractor



CASE IH Magnum 380 Tractor Price

The Case IH Magnum 380 Tractor Price $345,180.



CASE IH Magnum 380 Tractor Main Facts

  • Engine: Tier 4B with Selective Catalytic Reduction (SCR)
  • Maximum Engine HP: 415
  • PTO HP: 315
  • Standard Hitch Lift Capacity: 9026 kg
  • Cylinder: 6
  • Fuel Tank Capacity: Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)

CASE IH Magnum 380 Tractor Specifications

ENGINE
Engine Type Tier 4B with Selective Catalytic Reduction (SCR)
Engine HP @ rated 2000 RPM 380
Maximum Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 415
Maximum Boosted Engine HP @ rated 1,800 RPM ISO/ECE R120 (CV) 435
PTO HP @ rated 2000 RPM (Magnum 250 – 380) per SAE 315
Cylinders /Number of Valves /Displacement 6 cyl./24 Valves /8.7L
Engine Aspiration Turbocharger eVGT
Engine Compression Brake Optional
ElECTRICAL
Alternator (Amp) 200
Battery capacity 2-12V batteries
TRANSMISSION/PTO
Powershift: 18 Speed–25 MPH (40 kph) NA
Powershift: 19 Speed (Economy) –25 MPH (40 kph) NA
Powershift: 19 Speed–30 MPH (50 kph) NA
CVT Transmission–25 mph (40 kph) Standard
CVT Transmission: 30 mph (50 kph) Optional
Rear PTO – Standard/Optional 1,000 RPM 1 3/4 in. (44.5 mm) shafts / 540/1,000 RPM 1 3/8 in. (35 mm) shafts
AXLES
Rear Axle Diameter – Standard/Optional 5 in.(127 mm)/NA
Rear Axle Length – Standard 120 in. (3050 mm)/NA
Suspended Front Axle Optional
MFD Tread Adjustability 60–88 in. (1524–2235 mm)
MFD Duals Optional on Class 4.75 and Class 5 axles
Wheelbase – Powershift NA
Wheelbase – CVT 124 in. (3150 mm)
HYDRAULICS/HITCH
System Type Pressure Flow Compensating (PFC)
Remotes – Standard/Optional 4 Electro-hydraulic /5 or 6 Electro-hydraulic
Main Implement Pump Flow 44 gpm (166 L/min.) / 59 gpm (225 L/min.) or 75 gpm (282 L/min.)
Rear 3-pt Hitch Category Standard/Optional Cat IV/III/NA
Standard Hitch Lift Capacity 19,900 lbs (9 026 kg)
Optional Front 3-pt Hitch Lift Capacity 9,426 lbs. (4275 kg)
Front Hitch PTO Speed and Shaft Size 1,000 RPM 1 3/8 in. (35 mm) shaft 21 spline
CAPACITIES
Fuel Tank Powershift: 179 gal. (678L)/CVT: 163 gal. (617L)
Diesel Exhaust Fluid (DEF) Tank 26 gal. (99L)
CAB
Cab Suspension Optional
Volume (Size)/Glass (Area)/Cab Sound Level 109.5 cu ft. (3.1 m3 /68.5 sq. ft.)/67 dBa
WEIGHT
Average Standard Weight 32,200 lbs. (14148 kg)



Final Words

I hope you like this article, but if you have any problem regarding this article, then please comment for us we will solve your problem as soon as possible, Thanks for reading our article, and stay tuned with me for more stuff like this friends.

zala suraj

Leave a Reply

Your email address will not be published. Required fields are marked *
