YANMAR AP4 Rice Transplanter Specs Price in India 2020, Specifications, Review, Overview
This post all about the YANMAR AP4 Rice Transplanter price list, key features, Planting, horsepower, transmission, engine details, Condition for seeding and more.
YANMAR AP4 is a walk-behind four rows of rice transplanter, that can speed up the transplanting process in your field neatly. YANMAR AP4 Rice Transplanter use for working on the wet and not dry paddy field
Also Check: YANMAR Rice Transplanter VP Series
YANMAR Rice Transplanter AP4 Farm Machinery Price
For Price Please Contact us at your nearest dealer.
YANMAR Rice Transplanter AP4 Farm Machinery key features
- Engine Model: MZ175
- Displacement: 171 cu in.
- Fuel Tank capacity: 4 L
- Planting Method: Crank type
- Number of Gears: F2, R1
- Gasoline engine designed with hi-horsepower advanced OHV engine That provides low fuel consumption and powerful operation.
- Engine large fuel filler and 4 liter fuel tank, make comfortable refueling.
- That large diameter rubber flange wheels enhancing operations
- Dual adjustable ground clearance.
- Separable front hood cover
- Floating mechanism is more suitable for removing sludge.
YANMAR Rice Transplanter AP4 Farm Machinery Specification
| ENGINE | |
| Engine Model | MZ175 |
| Displacement, L(cu in.) | 171 |
| Output, kW (PS)/rpm | 2.6 KW (5.5ps)/3000rpm |
| Fuel | Petrol |
| Fuel Tank Capacity, L | 4 |
| Starting Method | Recoil rope starter |
| DRIVE LINE | |
| Tires Front | Rubber flanged tire |
| Tires Rear | NA |
| Steering | Side clutch lever |
| Number of Gears (Gears) | F2, R1 |
| Drive type | Mechanical |
| Tire Diameter | 660 |
| PLANTING | |
| Planting Method | Crank type |
| Number of Planting Rows, Rows | 4 |
| Interrow Planting Space ,cm | 30 |
| Planting Distance, cm | 22,17,15,12 |
| Number Of Seedlings (Seedling/3.3m2) | 50,65,75,90 |
| Depth of Planting, cm | 15 – 14 |
| Adjustment Per Seedling, Cross Feed, mm/rotation | 11 (26 times), 14 (20 times) |
| Adjustment Per Seedling, Vertical Scraping, mm | 8-17 |
| CONDITION FOR SEEDING | |
| Type of Seedling | young seedling, midium seedling |
| Plant Height | 2.0-4.5 leaves,8-25cm |
| Seedling Matt Size (long x wide x thickness) (cm) | 58 x 28 x 2-3cm |
| Operating Speed, m/s | 0.38-0.76 |
| Number Of Seeds, Boxes | 4 |
| DIMENSIONS | |
| Length – mm (ft in) | 2190 |
| Width – mm (ft in) | 1500 |
| Height – mm (ft in) | 1034 |
| Weight, kg (lb) | 145 |
Final Words
I think it should be enough information to you for your knowledge and buy or sell this YANMAR AP4 Transplanter farm Machinery. But if you have any problem regarding this article, then please comment below in the comment box. I will solve your problem as soon as possible, my friends and stay tuned with me for more stuff like this.
