McCormick B-Max T0-T2 Tractors Price, Specifications & Features 2024
McCormick B-Max T0-T2 Tractors Specs, Prices, Review, Features, Overview
The McCormick B-MAX T0-T2 new tractor family comes in both 2WD – and 4WD versions and is offered at a very attractive entry-level price.
Entirely built in Italy by Argo Tractors, the new McCormick B-MAX T0-T2 range delivers outstanding performance combined with high reliability and functionality.
McCormick B-Max T0-T2 series (B75B MAX, B85B MAX, B75 MAX, B85 MAX) Four models in the range are all powered by Perkins 1104 series 4-cylinder engines that produce high torque backup and quiet, eco-friendly performance while ensuring superior fuel economy.
The McCormick B-MAX B75B and McCormick B85B models feature Tier 0 engines, while the McCormick B-MAX B75 and McCormick B85 models are powered by engines meeting Tier 2 emissions regulations.
Here in this article, I am going to present the McCormick B-Max All Model such as B75B MAX, B85B MAX, B75 MAX, and B85 MAX Tractor information in detail such as price list, Technical Specifications, Key features, images and more.
That all kinds of information are reliable and genuine, I hope it is very helpful to you my friends. You can trust it because we always care about our site viewer. Ok friends let’s move on to our topic friends.
Also, Check McCormick other model Information
- McCormick X2 Series Tractor
- McCormick B-Max Series Tractor
- McCormick A-Max Series Tractor
- McCormick X5 series tractor
- McCormick X4 Series tractor
- McCormick X7 Pro Drive Series Tractor
McCormick B75B Max TIER 0 Tractor
McCormick B75b Max Tire 0 Tractor Key Features
- Engine: 11o4A-44 Direct injection Perkins engine
- Horsepower: 73.4Hp
- Rated speed: 2200 rpm
- Fuel Tank capacity: 90 Litres
- Base Gearbox: 12 forward and 4 reverse
- PTO: Mechanical Engagement Standard
- Brakes: Hydraulics Trailer braking system
McCormick B75b Max Tire 0 Price
I haven’t genuine Price so friends, please contact at your nearest dealer.
McCormick B75B Max TIER 0 Specs
| ENGINE | |
| DIRECT-INJECTION PERKINS ENGINE | 1104A-44 |
| MAX. POWER (ISO) | 73.4 HP/ /54 KW |
| RATED SPEED | 2200 RPM |
| MAX. TORQUE | 203 LB(275 Nm) |
| MAX. TORQUE-SPEED | 1400 RPM |
| BORE/STROKE | 4/5 in. (105/127 MM) |
| DISPLACEMENT/NR. OF CYLINDERS CU. IN. (CM3 ) | 268,5(4400)/4 |
| COMPRESSION RATIO | 19.25:1 |
| WATER COOLING | Standard |
| AIR FILTER | Standard |
| FUEL TANK CAPACITY | 24 Gal.(90 Litres) |
| TRANSMISSION | |
| BASE GEARBOX: 12FWD + 4REV | Standard |
| REVERSE SHUTTLE + BASE GEARBOX: 12FWD + 12REV | Option |
| REVERSE SHUTTLE + BASE GEARBOX + CREEPER: 16FWD + 16REV | Option |
| REAR MECHANICAL DIFF-LOCK | Standard |
| REAR HYDRAULIC DIFF-LOCK | Option |
| CLUTCH | |
| INDEPENDENT DRY DUAL CLUTCH IN. (MM) | 12 (3048) |
| MECHANICAL ENGAGEMENT | Standard |
| POWER TAKE OFF | |
| MECHANICAL ENGAGEMENT | Standard |
| 1 SPEEDS 540 RPM | Standard |
| 2 SPEEDS 540/750 RPM | Option |
| 2 SPEEDS 540/1000 RPM | Option |
| 1”3/8 (34,9 MM) PTO SHAFT WITH 6 SPLINES | Standard |
| GROUND SPEED PTO | Standard |
| NET PTO POWER ISO | 68,5HP/50,5KW |
| 4WD FRONT AXLE | |
| HYDROSTATIC STEERING SYSTEM | Standard |
| EPICYCLIC FINAL DRIVES | Standard |
| 4WD MECHANICAL ENGAGEMENT | Standard |
| MAXIMUM STEERING ANGLE | 55° |
| TWIN-LOCK HYDRAULIC DIFF LOCK | Option |
| BRAKES | |
| MECHANICAL ENGAGEMENT | Standard |
| OIL-BATH GRAPHITE-COATED REAR BRAKES – 10 DISCS | Standard |
| HYDRAULIC TRAILER BRAKING SYSTEM | Option |
| HYDRAULIC POWER LIFT | |
| FUNCTIONS: POSITION CONTROL, DRAFT, INTERMIX, FLOATING POSIT | Option |
| MECHANICAL | Option |
| STD LIFTING POWER LB. (KG) | 6600 (3000) |
| LIFTING POWER WITH 2 ADDITIONAL CYLINDERS LB. (KG) | 9944 (4520)Option |
| MAX. OPERATING PRESSURE PSI (BAR) | 2600 (180) |
| TOTAL HYDRAULIC FLOW (HITCH + STEERING) GPM (LT/MIN) | 13.8+6.4 (52.3+24.2) |
| CAT 2 THREE-POINT LINKAGE | Standard |
| STANDARD AUXILIARY VALVES STD / OPT | 1 / 2 |
| DRIVING SEAT | |
| FIXED FOOTBOARDS | Standard |
| SIDE GEAR LEVERS | Standard |
| 2 POST SAFETY FRAME | Standard |
| STANDARD SPRUNG SEAT | Standard |
| ANALOGIC CONTROL PANEL | Standard |
| RIGID SUNROOF | Option |
| WEIGHTS AND DIMENSIONS (IN RUNNING ORDER) | |
| FRONT TYRES 2WD | 9.00-16 |
| FRONT TYRES 4WD | 12.4-24 |
| REAR TYRES 4WD | 18.4-30 |
| TOTAL LENGTH WITHOUT BALLAST IN. (MM) | 150 (3810) |
| WHEELBASE 2WD/4WD IN. (MM) | 91.7/91.2 (2330/2317) |
| HEIGHT AT STEERING WHEEL IN. (MM) | 67.7 (1720) |
| MAX GROUND CLEARANCE 4WD IN. (MM) | 19.9 (430) |
| HEIGHT TO SAFETY FRAME IN. (MM) | 102 (2590) |
| MINIMUM WIDTH IN. (MM) | 73.6 (1870) |
| MINIMUM TURNING RADIUS (WITHOUT BRAKES) 2WD/4WD IN. (MM) | 157.4 (4000) / 181 (4600) |
| WEIGHT (WITHOUT BALLAST) 4WD LB. (KG) | 6923 (3147) |
| TRACKS | |
| FRONT TRACK ADJUSTMENT 2WD IN. (MM) | 52/71.6 (1320/1820) |
| FRONT TRACK ADJUSTMENT 4WD IN. (MM) | 55.6/76.9 (1440/1954) |
| REAR TRACK ADJUSTMENT IN. (MM) | 55.1/78.7 (1608/2008) |
| OPTIONAL TYRES AND WHEELS | |
| FRONT / REAR 2WD | 9.00-16 / 18.4R30 |
| FRONT / REAR 2WD | 7.50-20 / 13.6R38 |
| FRONT / REAR 2WD | 7.50-16 / 16.9R30 |
| FRONT / REAR 4WD | 11.2R24 / 16.9R30 |
| FRONT / REAR 4WD | 12.4R24 / 13.6R38 |
| FRONT / REAR 4WD | 13.6R24 / 16.9R34 |
| FRONT / REAR 4WD | 380/70R24 / 480/70R34 |
| FRONT / REAR 4WD | 320/70R24 / 16.9R30 |
| FRONT / REAR 4WD | 12.4R24 / 18.4R30 |
| OPTIONAL | |
| FRONT BALLASTS OF 79.2 LB. (36 KG) EACH | 7 |
| REAR BALLASTS OF 132 LB. (60 KG) EACH | 2 / 4 |
| FRONT FENDER | Option |
McCormick B85B Max TIER 0 Tractor
McCormick B85b Max Tire 0 Tractor Key Features
- Engine: 11o4A-44 Direct injection Perkins engine
- Horsepower: 83.6 Hp
- Rated speed: 2200 rpm
- Fuel Tank capaLitres90 Litres
- Base Gearbox: 12 forward and 4 reverse
- PTO: Mechanical Engagement standard
- Brakes: Oil Bath Graphite-Coated Rear Brakes -10 Discs Standard
McCormick B85b Max Tire 0 Price
I haven’t genuine Price so friends, please contact your nearest dealer.
McCormick B85B Max TIER 0 Specs
| ENGINE | |
| DIRECT-INJECTION PERKINS ENGINE | 1104A-44 |
| MAX. POWER (ISO) | 83.6 HP/ /61.5 KW |
| RATED SPEED | 2200 RPM |
| MAX. TORQUE | 214 LB((289 Nm) |
| MAX. TORQUE-SPEED | 1400 RPM |
| BORE/STROKE | 4/5 in. (105/127 MM) |
| DISPLACEMENT/NR. OF CYLINDERS CU. IN. (CM3 ) | 268,5(4400)/4 |
| COMPRESSION RATIO | 19.25:1 |
| WATER COOLING | Standard |
| AIR FILTER | Standard |
| FUEL TANK CAPACITY | 24 Gal.(90 Litres) |
| TRANSMISSION | |
| BASE GEARBOX: 12FWD + 4REV | Standard |
| REVERSE SHUTTLE + BASE GEARBOX: 12FWD + 12REV | Option |
| REVERSE SHUTTLE + BASE GEARBOX + CREEPER: 16FWD + 16REV | Option |
| REAR MECHANICAL DIFF-LOCK | Standard |
| REAR HYDRAULIC DIFF-LOCK | Option |
| CLUTCH | |
| INDEPENDENT DRY DUAL CLUTCH IN. (MM) | 12 (3048) |
| MECHANICAL ENGAGEMENT | Standard |
| POWER TAKE OFF | |
| MECHANICAL ENGAGEMENT | Standard |
| 1 SPEEDS 540 RPM | Standard |
| 2 SPEEDS 540/750 RPM | Option |
| 2 SPEEDS 540/1000 RPM | Option |
| 1”3/8 (34,9 MM) PTO SHAFT WITH 6 SPLINES | Standard |
| GROUND SPEED PTO | Standard |
| NET PTO POWER ISO | 76HP/56,5KW |
| 4WD FRONT AXLE | |
| HYDROSTATIC STEERING SYSTEM | Standard |
| EPICYCLIC FINAL DRIVES | Standard |
| 4WD MECHANICAL ENGAGEMENT | Standard |
| MAXIMUM STEERING ANGLE | 55° |
| TWIN-LOCK HYDRAULIC DIFF LOCK | Option |
| BRAKES | |
| MECHANICAL ENGAGEMENT | Standard |
| OIL-BATH GRAPHITE-COATED REAR BRAKES – 10 DISCS | Standard |
| HYDRAULIC TRAILER BRAKING SYSTEM | Option |
| HYDRAULIC POWER LIFT | |
| FUNCTIONS: POSITION CONTROL, DRAFT, INTERMIX, FLOATING POSIT | Option |
| MECHANICAL | Option |
| STD LIFTING POWER LB. (KG) | 6600 (3000) |
| LIFTING POWER WITH 2 ADDITIONAL CYLINDERS LB. (KG) | 9944 (4520)Option |
| MAX. OPERATING PRESSURE PSI (BAR) | 2600 (180) |
| TOTAL HYDRAULIC FLOW (HITCH + STEERING) GPM (LT/MIN) | 13.8+6.4 (52.3+24.2) |
| CAT 2 THREE-POINT LINKAGE | Standard |
| STANDARD AUXILIARY VALVES STD / OPT | 1 / 2 |
| DRIVING SEAT | |
| FIXED FOOTBOARDS | Standard |
| SIDE GEAR LEVERS | Standard |
| 2 POST SAFETY FRAME | Standard |
| STANDARD SPRUNG SEAT | Standard |
| ANALOGIC CONTROL PANEL | Standard |
| RIGID SUNROOF | Option |
| WEIGHTS AND DIMENSIONS (IN RUNNING ORDER) | |
| FRONT TYRES 2WD | 9.00-16 |
| FRONT TYRES 4WD | 12.4-24 |
| REAR TYRES 4WD | 18.4-30 |
| TOTAL LENGTH WITHOUT BALLAST IN. (MM) | 150 (3810) |
| WHEELBASE 2WD/4WD IN. (MM) | 91.7/91.2 (2330/2317) |
| HEIGHT AT STEERING WHEEL IN. (MM) | 67.7 (1720) |
| MAX GROUND CLEARANCE 4WD IN. (MM) | 19.9 (430) |
| HEIGHT TO SAFETY FRAME IN. (MM) | 102 (2590) |
| MINIMUM WIDTH IN. (MM) | 73.6 (1870) |
| MINIMUM TURNING RADIUS (WITHOUT BRAKES) 2WD/4WD IN. (MM) | 157.4 (4000) / 181 (4600) |
| WEIGHT (WITHOUT BALLAST) 4WD LB. (KG) | 6923 (3147) |
| TRACKS | |
| FRONT TRACK ADJUSTMENT 2WD IN. (MM) | 52/71.6 (1320/1820) |
| FRONT TRACK ADJUSTMENT 4WD IN. (MM) | 55.6/76.9 (1440/1954) |
| REAR TRACK ADJUSTMENT IN. (MM) | 55.1/78.7 (1608/2008) |
| OPTIONAL TYRES AND WHEELS | |
| FRONT / REAR 2WD | 9.00-16 / 18.4R30 |
| FRONT / REAR 2WD | 7.50-20 / 13.6R38 |
| FRONT / REAR 2WD | 7.50-16 / 16.9R30 |
| FRONT / REAR 4WD | 11.2R24 / 16.9R30 |
| FRONT / REAR 4WD | 12.4R24 / 13.6R38 |
| FRONT / REAR 4WD | 13.6R24 / 16.9R34 |
| FRONT / REAR 4WD | 380/70R24 / 480/70R34 |
| FRONT / REAR 4WD | 320/70R24 / 16.9R30 |
| FRONT / REAR 4WD | 12.4R24 / 18.4R30 |
| OPTIONAL | |
| FRONT BALLASTS OF 79.2 LB. (36 KG) EACH | 7 |
| REAR BALLASTS OF 132 LB. (60 KG) EACH | 2 / 4 |
| FRONT FENDER | Option |
McCormick B75 Max TIER 2 Tractor
McCormick B75 Max Tire 2 Tractor Key Features
- Engine: 11o4C-44 Direct injection Perkins engine
- Horsepower: 73.4 Hp
- Rated speed: 2200 rpm
- Fuel Tank capaLitres90 Litres
- Base Gearbox: 12 forward and 4 reverse
- PTO: Mechanical Engagement standard
- Brakes: Oil Bath Graphite-Coated Rear Brakes -10 Discs Standard
McCormick B75 Max Tire 2 Price
I haven’t genuine Price so friends, please contact your nearest dealer.
McCormick B75 Max TIER 2 Specs
| ENGINE | |
| DIRECT-INJECTION PERKINS ENGINE | 1104A-44 |
| MAX. POWER (ISO) | 73.4 HP/ 54 KW |
| RATED SPEED | 2200 RPM |
| MAX. TORQUE | 218 LB((294 Nm) |
| MAX. TORQUE-SPEED | 1400 RPM |
| BORE/STROKE | 4/5 in. (105/127 MM) |
| DISPLACEMENT/NR. OF CYLINDERS CU. IN. (CM3 ) | 268,5(4400)/4 |
| COMPRESSION RATIO | 19.3:1 |
| WATER COOLING | Standard |
| AIR FILTER | Standard |
| FUEL TANK CAPACITY | 24 Gal.(90 Litres) |
| TRANSMISSION | |
| BASE GEARBOX: 12FWD + 4REV | Standard |
| REVERSE SHUTTLE + BASE GEARBOX: 12FWD + 12REV | Option |
| REVERSE SHUTTLE + BASE GEARBOX + CREEPER: 16FWD + 16REV | Option |
| REAR MECHANICAL DIFF-LOCK | Standard |
| REAR HYDRAULIC DIFF-LOCK | Option |
| CLUTCH | |
| INDEPENDENT DRY DUAL CLUTCH IN. (MM) | 12 (3048) |
| MECHANICAL ENGAGEMENT | Standard |
| POWER TAKE OFF | |
| MECHANICAL ENGAGEMENT | Standard |
| 1 SPEEDS 540 RPM | Standard |
| 2 SPEEDS 540/750 RPM | Option |
| 2 SPEEDS 540/1000 RPM | Option |
| 1”3/8 (34,9 MM) PTO SHAFT WITH 6 SPLINES | Standard |
| GROUND SPEED PTO | Standard |
| NET PTO POWER ISO | 68,5HP/50,5KW |
| 4WD FRONT AXLE | |
| HYDROSTATIC STEERING SYSTEM | Standard |
| EPICYCLIC FINAL DRIVES | Standard |
| 4WD MECHANICAL ENGAGEMENT | Standard |
| MAXIMUM STEERING ANGLE | 55° |
| TWIN-LOCK HYDRAULIC DIFF LOCK | Option |
| BRAKES | |
| MECHANICAL ENGAGEMENT | Standard |
| OIL-BATH GRAPHITE-COATED REAR BRAKES – 10 DISCS | Standard |
| HYDRAULIC TRAILER BRAKING SYSTEM | Option |
| HYDRAULIC POWER LIFT | |
| FUNCTIONS: POSITION CONTROL, DRAFT, INTERMIX, FLOATING POSIT | Option |
| MECHANICAL | Option |
| STD LIFTING POWER LB. (KG) | 6600 (3000) |
| LIFTING POWER WITH 2 ADDITIONAL CYLINDERS LB. (KG) | 9944 (4520)Option |
| MAX. OPERATING PRESSURE PSI (BAR) | 2600 (180) |
| TOTAL HYDRAULIC FLOW (HITCH + STEERING) GPM (LT/MIN) | 13.8+6.4 (52.3+24.2) |
| CAT 2 THREE-POINT LINKAGE | Standard |
| STANDARD AUXILIARY VALVES STD / OPT | 1 / 2 |
| DRIVING SEAT | |
| FIXED FOOTBOARDS | Standard |
| SIDE GEAR LEVERS | Standard |
| 2 POST SAFETY FRAME | Standard |
| STANDARD SPRUNG SEAT | Standard |
| ANALOGIC CONTROL PANEL | Standard |
| RIGID SUNROOF | Option |
| WEIGHTS AND DIMENSIONS (IN RUNNING ORDER) | |
| FRONT TYRES 2WD | 9.00-16 |
| FRONT TYRES 4WD | 12.4-24 |
| REAR TYRES 4WD | 18.4-30 |
| TOTAL LENGTH WITHOUT BALLAST IN. (MM) | 150 (3810) |
| WHEELBASE 2WD/4WD IN. (MM) | 91.7/91.2 (2330/2317) |
| HEIGHT AT STEERING WHEEL IN. (MM) | 67.7 (1720) |
| MAX GROUND CLEARANCE 4WD IN. (MM) | 19.9 (430) |
| HEIGHT TO SAFETY FRAME IN. (MM) | 102 (2590) |
| MINIMUM WIDTH IN. (MM) | 73.6 (1870) |
| MINIMUM TURNING RADIUS (WITHOUT BRAKES) 2WD/4WD IN. (MM) | 157.4 (4000) / 181 (4600) |
| WEIGHT (WITHOUT BALLAST) 4WD LB. (KG) | 6923 (3147) |
| TRACKS | |
| FRONT TRACK ADJUSTMENT 2WD IN. (MM) | 52/71.6 (1320/1820) |
| FRONT TRACK ADJUSTMENT 4WD IN. (MM) | 55.6/76.9 (1440/1954) |
| REAR TRACK ADJUSTMENT IN. (MM) | 55.1/78.7 (1608/2008) |
| OPTIONAL TYRES AND WHEELS | |
| FRONT / REAR 2WD | 9.00-16 / 18.4R30 |
| FRONT / REAR 2WD | 7.50-20 / 13.6R38 |
| FRONT / REAR 2WD | 7.50-16 / 16.9R30 |
| FRONT / REAR 4WD | 11.2R24 / 16.9R30 |
| FRONT / REAR 4WD | 12.4R24 / 13.6R38 |
| FRONT / REAR 4WD | 13.6R24 / 16.9R34 |
| FRONT / REAR 4WD | 380/70R24 / 480/70R34 |
| FRONT / REAR 4WD | 320/70R24 / 16.9R30 |
| FRONT / REAR 4WD | 12.4R24 / 18.4R30 |
| OPTIONAL | |
| FRONT BALLASTS OF 79.2 LB. (36 KG) EACH | 7 |
| REAR BALLASTS OF 132 LB. (60 KG) EACH | 2 / 4 |
| FRONT FENDER | Option |
McCormick B85 Max TIER 2 Tractor
McCormick B85 Max Tire 2 Tractor Key Features
- Engine: 11o4C-44 Direct injection Perkins engine
- Horsepower: 73.4 Hp
- Rated speed: 2200 rpm
- Fuel Tank capaLitres90 Litres
- Base Gearbox: 12 forward and 4 reverse
- PTO: Mechanical Engagement standard
- Brakes: Oil Bath Graphite-Coated Rear Brakes -10 Discs Standard
McCormick B85 Max Tire 2 Price
I haven’t genuine Price so friends, please contact us at your nearest dealer.
McCormick B85 Max TIER 2 Specs
| ENGINE | |
| DIRECT-INJECTION PERKINS ENGINE | 1104A-44 |
| MAX. POWER (ISO) | 81.6 HP/ 60 KW |
| RATED SPEED | 2200 RPM |
| MAX. TORQUE | 218 LB((294 Nm) |
| MAX. TORQUE-SPEED | 1400 RPM |
| BORE/STROKE | 4/5 in. (105/127 MM) |
| DISPLACEMENT/NR. OF CYLINDERS CU. IN. (CM3 ) | 268,5(4400)/4 |
| COMPRESSION RATIO | 19.3:1 |
| WATER COOLING | Standard |
| AIR FILTER | Standard |
| FUEL TANK CAPACITY | 24 Gal.(90 Litres) |
| TRANSMISSION | |
| BASE GEARBOX: 12FWD + 4REV | Standard |
| REVERSE SHUTTLE + BASE GEARBOX: 12FWD + 12REV | Option |
| REVERSE SHUTTLE + BASE GEARBOX + CREEPER: 16FWD + 16REV | Option |
| REAR MECHANICAL DIFF-LOCK | Standard |
| REAR HYDRAULIC DIFF-LOCK | Option |
| CLUTCH | |
| INDEPENDENT DRY DUAL CLUTCH IN. (MM) | 12 (3048) |
| MECHANICAL ENGAGEMENT | Standard |
| POWER TAKE OFF | |
| MECHANICAL ENGAGEMENT | Standard |
| 1 SPEEDS 540 RPM | Standard |
| 2 SPEEDS 540/750 RPM | Option |
| 2 SPEEDS 540/1000 RPM | Option |
| 1”3/8 (34,9 MM) PTO SHAFT WITH 6 SPLINES | Standard |
| GROUND SPEED PTO | Standard |
| NET PTO POWER ISO | 75,5HP/55,5KW |
| 4WD FRONT AXLE | |
| HYDROSTATIC STEERING SYSTEM | Standard |
| EPICYCLIC FINAL DRIVES | Standard |
| 4WD MECHANICAL ENGAGEMENT | Standard |
| MAXIMUM STEERING ANGLE | 55° |
| TWIN-LOCK HYDRAULIC DIFF LOCK | Option |
| BRAKES | |
| MECHANICAL ENGAGEMENT | Standard |
| OIL-BATH GRAPHITE-COATED REAR BRAKES – 10 DISCS | Standard |
| HYDRAULIC TRAILER BRAKING SYSTEM | Option |
| HYDRAULIC POWER LIFT | |
| FUNCTIONS: POSITION CONTROL, DRAFT, INTERMIX, FLOATING POSIT | Option |
| MECHANICAL | Option |
| STD LIFTING POWER LB. (KG) | 6600 (3000) |
| LIFTING POWER WITH 2 ADDITIONAL CYLINDERS LB. (KG) | 9944 (4520)Option |
| MAX. OPERATING PRESSURE PSI (BAR) | 2600 (180) |
| TOTAL HYDRAULIC FLOW (HITCH + STEERING) GPM (LT/MIN) | 13.8+6.4 (52.3+24.2) |
| CAT 2 THREE-POINT LINKAGE | Standard |
| STANDARD AUXILIARY VALVES STD / OPT | 1 / 2 |
| DRIVING SEAT | |
| FIXED FOOTBOARDS | Standard |
| SIDE GEAR LEVERS | Standard |
| 2 POST SAFETY FRAME | Standard |
| STANDARD SPRUNG SEAT | Standard |
| ANALOGIC CONTROL PANEL | Standard |
| RIGID SUNROOF | Option |
| WEIGHTS AND DIMENSIONS (IN RUNNING ORDER) | |
| FRONT TYRES 2WD | 9.00-16 |
| FRONT TYRES 4WD | 12.4-24 |
| REAR TYRES 4WD | 18.4-30 |
| TOTAL LENGTH WITHOUT BALLAST IN. (MM) | 150 (3810) |
| WHEELBASE 2WD/4WD IN. (MM) | 91.7/91.2 (2330/2317) |
| HEIGHT AT STEERING WHEEL IN. (MM) | 67.7 (1720) |
| MAX GROUND CLEARANCE 4WD IN. (MM) | 19.9 (430) |
| HEIGHT TO SAFETY FRAME IN. (MM) | 102 (2590) |
| MINIMUM WIDTH IN. (MM) | 73.6 (1870) |
| MINIMUM TURNING RADIUS (WITHOUT BRAKES) 2WD/4WD IN. (MM) | 157.4 (4000) / 181 (4600) |
| WEIGHT (WITHOUT BALLAST) 4WD LB. (KG) | 6923 (3147) |
| TRACKS | |
| FRONT TRACK ADJUSTMENT 2WD IN. (MM) | 52/71.6 (1320/1820) |
| FRONT TRACK ADJUSTMENT 4WD IN. (MM) | 55.6/76.9 (1440/1954) |
| REAR TRACK ADJUSTMENT IN. (MM) | 55.1/78.7 (1608/2008) |
| OPTIONAL TYRES AND WHEELS | |
| FRONT / REAR 2WD | 9.00-16 / 18.4R30 |
| FRONT / REAR 2WD | 7.50-20 / 13.6R38 |
| FRONT / REAR 2WD | 7.50-16 / 16.9R30 |
| FRONT / REAR 4WD | 11.2R24 / 16.9R30 |
| FRONT / REAR 4WD | 12.4R24 / 13.6R38 |
| FRONT / REAR 4WD | 13.6R24 / 16.9R34 |
| FRONT / REAR 4WD | 380/70R24 / 480/70R34 |
| FRONT / REAR 4WD | 320/70R24 / 16.9R30 |
| FRONT / REAR 4WD | 12.4R24 / 18.4R30 |
| OPTIONAL | |
| FRONT BALLASTS OF 79.2 LB. (36 KG) EACH | 7 |
| REAR BALLASTS OF 132 LB. (60 KG) EACH | 2 / 4 |
| FRONT FENDER | Option |
Conclusion
I think it should be enough information for you to buy or sell this new McCormick B-Max T0-T2 Series tractors, But if you have any queries about this post, then please comment in the comment section, I will solve your problem as soon as. thanks for visiting our site friends.
