The KIOTI NX Series with Daedong ECO Technology. It’s all models ranging from 45 hp to 60 hp, this Kioti NX series of high-performance eco-friendly utility tractors gives power and fuel efficiency into one reliable workhorse.

Are you thinking to buy Kioti NX Series 5510 and 6010 tractor? And do you want to know about the Kioti NX 5510 and 6010 Tractors Price List, Key features? So you are at a genuine place. Here in this article,

I am going to introduce the Kioti NX series 5510 and 6010 model tractors information such as price list, engine details, hydraulics performance, mileage, power take-off, transmission system, tire size, fuel system, dimensions and more.

Also Check:

Now check out the Kioti NX Series Tractors each single model information in details

Kioti NX5510 Tractor

Kioti NX5510 Tractor

Kioti NX5510 Tractor Key Features

  • Engine Gross Horsepower: 55 hp
  • Transmission Type: 24 x 24 Manual Transmission
  • PTO Type: Independent
  • Shuttle:Dry Type Single Plate
  • PTO Horsepower: 46 hp
  • Lifting Capacity: 1441 kg

Kioti NX5510 Tractor Price

The Kioti NX5510 Tractor price will be $28,999.

Kioti NX5510 Tractor Specifications

ENGINE
Engine Model3F183T
Engine Gross Power55 hp (41 kW)
Rated Speed2,600 rpm
No. of Cylinders3
Fuel TypeDiesel
AspirationTurbo Charged
Displacement111.4 cu. in. (1,826 cc)
Fuel Tank Capacity14.8 gal. (56 L)
TRANSMISSION
Transmission TypeManual
ShuttleSynchronized
Main GearSynchronized
No. of Travel Speeds – Forward / Reverse24 x 24
Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed0.12 mph (0.19 km/h)
Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed17.35 mph (27.93 km/h)
BrakesWet Multi Disc
ClutchDry Single Plate
HYDRAULICS
PumpGear
Pump Capacity (Max. Flow Rate)16.5 gpm (62.4 L/min)
POWER TAKE OFF
PTO Type TransIndependent
PTO Power46 hp (34.3 kW)
Rear PTO Speeds(1st)540 rpm
Mid PTO Speeds2,000 rpm (Optional)
DIMENSIONS W/AG TIRE
Length w/ 3-point hitch139.6 in. (3,547 mm)
Width65.7 in. (1,669 mm)
Height from Top of ROPS Cab103.1 in. (2,618 mm)
From Top of the Highest PointNA
Wheelbase75.6 in. (1,920 mm)
Ground Clearance15.7 in. (400 mm)
Front Tread Ag Tires – Min53.3 in. (1,355 mm)
Rear Tread Ag Tires – Min52.1 in. (1,324 mm)
Turning Radius w/ Brake9.97 ft. (3.04 m)
Weight w/ Ag Tires w/ Cab4,194 lbs. (1,902.4 kg)
3-POINT HITCH
Standard CategoryCategory I & II
Lift Capacity, 24″ aft of hitch, lb(kg)3,177 lbs. (1,441 kg)
Control TypePosition with Draft Control
TIRE SIZE
Agricultural
Front9.5-16
Rear16.9-24
Truf
Front29-12.5-15
Rear21.5L-16.1
Industrial
Front10-16.5
Rear17.5-24


Kioti NX5510 CAB Tractor

Kioti NX5510 CAB Tractor

Kioti NX5510 CAB Tractor Key Features

  • Engine Gross Horsepower: 55 hp
  • Transmission Type: 24 x 24 Manual Transmission
  • PTO Type: Independent
  • Shuttle: Synchronized
  • PTO Horsepower: 46 hp
  • Lifting Capacity: 1441 kg

More Post:

 Find Here:

Kioti NX5510 CAB Tractor Price

The Kioti NX5510 CAB Tractor price will be $29,999.

Kioti NX5510 CAB Tractor Specifications

ENGINE
Engine Model3F183T
Engine Gross Power55 hp (41 kW)
Rated Speed2,600 rpm
No. of Cylinders3
Fuel TypeDiesel
AspirationTurbo Charged
Displacement111.4 cu. in. (1,826 cc)
Fuel Tank Capacity14.8 gal. (56 L)
TRANSMISSION
Transmission TypeManual
ShuttleSynchronized
Main GearSynchronized
No. of Travel Speeds – Forward / Reverse24 x 24
Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed0.12 mph (0.19 km/h)
Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed17.35 mph (27.93 km/h)
BrakesWet Multi Disc
ClutchDry Single Plate
HYDRAULICS
PumpGear
Pump Capacity (Max. Flow Rate)16.5 gpm (62.4 L/min)
POWER TAKE OFF
PTO Type TransIndependent
PTO Power46 hp (34.3 kW)
Rear PTO Speeds(1st)540 rpm
Mid PTO Speeds2,000 rpm (Optional)
DIMENSIONS W/AG TIRE
Length w/ 3-point hitch139.6 in. (3,547 mm)
Width65.7 in. (1,669 mm)
Height from Top of ROPS Cab94.1 in. (2,390 mm)
From Top of the Highest PointNA
Wheelbase75.6 in. (1,920 mm)
Ground Clearance15.7 in. (400 mm)
Front Tread Ag Tires – Min53.3 in. (1,355 mm)
Rear Tread Ag Tires – Min52.5 in. (1,324 mm)
Turning Radius w/ Brake9.97 ft. (3.04 m)
Weight w/ Ag Tires w/ Cab4,551 lbs. (2,064.3 kg)
3-POINT HITCH
Standard CategoryCategory I & II
Lift Capacity, 24″ aft of hitch, lb(kg)3,177 lbs. (1,441 kg)
Control TypePosition with Draft Control
TIRE SIZE
Agricultural
Front9.5-16
Rear16.9-24
Truf
Front29-12.5-15
Rear21.5L-16.1
Industrial
Front10-16.5
Rear17.5-24


Kioti NX5510 hst Tractor

Kioti NX5510 hst Tractor

Kioti NX5510 hst Tractor Key Features

  • Engine Gross Horsepower: 55 hp
  • Transmission Type: Hydrostatic
  • PTO Type: Independent
  • Shuttle:NA
  • PTO Horsepower: 43.1 hp
  • Lifting Capacity: 1441 kg

Kioti NX5510 hst Tractor Price

The Kioti NX5510 hst Tractor price will be $28,999.

Kioti NX5510 hst Tractor Specifications

ENGINE
Engine Model3F183T
Engine Gross Power55 hp (41 kW)
Rated Speed2,600 rpm
No. of Cylinders3
Fuel TypeDiesel
AspirationTurbo Charged
Displacement111.4 cu. in. (1,826 cc)
Fuel Tank Capacity14.8 gal. (56 L)
TRANSMISSION
Transmission TypeHydrostatic
ShuttleNA
Main GearNA
No. of Travel Speeds – Forward / Reverse3 Range
Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed18.26 mph (29.38 km/h)
BrakesWet Multi Disc
ClutchNA
HYDRAULICS
PumpGear
Pump Capacity (Max. Flow Rate)17.9 gpm (67.6 L/min)
POWER TAKE OFF
PTO Type TransIndependent
PTO Power43.1 hp (32.1 kW)
Rear PTO Speeds(1st)540 rpm
Mid PTO Speeds2,000 rpm (Optional)
DIMENSIONS W/AG TIRE
Length w/ 3-point hitch139.6 in. (3,547 mm)
Width65.7 in. (1,669 mm)
Height from Top of ROPS Cab103.1 in. (2,618 mm)
From Top of the Highest PointNA
Wheelbase75.6 in. (1,920 mm)
Ground Clearance15.7 in. (400 mm)
Front Tread Ag Tires – Min53.3 in. (1,355 mm)
Rear Tread Ag Tires – Min52.5 in. (1,324 mm)
Turning Radius w/ Brake9.97 ft. (3.04 m)
Weight w/ Ag Tires w/ Cab4,183 lbs. (1,897.4 kg)
3-POINT HITCH
Standard CategoryCategory I & II
Lift Capacity, 24″ aft of hitch, lb(kg)3,177 lbs. (1,441 kg)
Control TypePosition with Draft Control
TIRE SIZE
Agricultural
Front9.5-16
Rear16.9-24
Truf
Front29-12.5-15
Rear21.5L-16.1
Industrial
Front10-16.5
Rear17.5-24


Kioti NX5510 hst CAB Tractor

Kioti NX5510 hst CAB Tractor

Kioti NX5510 hst CAB Tractor Key Features

  • Engine Gross Horsepower: 55 hp
  • Transmission Type: Hydrostatic
  • PTO Type: Independent
  • Shuttle:NA
  • PTO Horsepower: 43.1 hp
  • Lifting Capacity: 1441 kg

Kioti NX5510 hst CAB Tractor Price

The Kioti NX5510 hst CAB Tractor price will be $29,999.

Kioti NX5510 hst CAB Tractor Specifications

ENGINE
Engine Model3F183T
Engine Gross Power55 hp (41 kW)
Rated Speed2,600 rpm
No. of Cylinders3
Fuel TypeDiesel
AspirationTurbo Charged
Displacement111.4 cu. in. (1,826 cc)
Fuel Tank Capacity14.8 gal. (56 L)
TRANSMISSION
Transmission TypeHydrostatic
ShuttleNA
Main GearNA
No. of Travel Speeds – Forward / Reverse3 Range
Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed18.26 mph (29.38 km/h)
BrakesWet Multi Disc
ClutchNA
HYDRAULICS
PumpGear
Pump Capacity (Max. Flow Rate)17.9 gpm (67.6 L/min)
POWER TAKE OFF
PTO Type TransIndependent
PTO Power43.1 hp (32.1 kW)
Rear PTO Speeds(1st)540 rpm
Mid PTO Speeds2,000 rpm (Optional)
DIMENSIONS W/AG TIRE
Length w/ 3-point hitch139.6 in. (3,547 mm)
Width65.7 in. (1,669 mm)
Height from Top of ROPS Cab94.1 in. (2,390 mm)
From Top of the Highest PointNA
Wheelbase75.6 in. (1,920 mm)
Ground Clearance15.7 in. (400 mm)
Front Tread Ag Tires – Min53.3 in. (1,355 mm)
Rear Tread Ag Tires – Min52.5 in. (1,324 mm)
Turning Radius w/ Brake9.97 ft. (3.04 m)
Weight w/ Ag Tires w/ Cab4,520 lbs. (2,050.3 kg)
3-POINT HITCH
Standard CategoryCategory I & II
Lift Capacity, 24″ aft of hitch, lb(kg)3,177 lbs. (1,441 kg)
Control TypePosition with Draft Control
TIRE SIZE
Agricultural
Front9.5-16
Rear16.9-24
Truf
Front29-12.5-15
Rear21.5L-16.1
Industrial
Front10-16.5
Rear17.5-24


Kioti NX6010 hst Tractor

Kioti NX6010 hst Tractor

Kioti NX6010 hst Tractor Key Features

  • Engine Gross Horsepower: 60 hp
  • Transmission Type: Hydrostatic
  • PTO Type: Independent
  • Shuttle:NA
  • PTO Horsepower: 48.3 hp
  • Lifting Capacity: 1441 kg

Kioti NX6010 hst Tractor Price

The Kioti NX6010 hst Tractor price will be $29,900.

Kioti NX6010 hst Tractor Specifications

ENGINE
Engine Model3F183T
Engine Gross Power60 hp (44.7 kW)
Rated Speed2,600 rpm
No. of Cylinders3
Fuel TypeDiesel
AspirationTurbo Charged
Displacement111.4 cu. in. (1,826 cc)
Fuel Tank Capacity14.8 gal. (56 L)
TRANSMISSION
Transmission TypeHydrostatic
ShuttleNA
Main GearNA
No. of Travel Speeds – Forward / Reverse3 Range
Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed18.26 mph (29.38 km/h)
BrakesWet Multi Disc
ClutchNA
HYDRAULICS
PumpGear
Pump Capacity (Max. Flow Rate)17.9 gpm (67.6 L/min)
POWER TAKE OFF
PTO Type TransIndependent
PTO Power48.3 hp (36 kW)
Rear PTO Speeds(1st)540 rpm
Mid PTO Speeds2,000 rpm (Optional)
DIMENSIONS W/AG TIRE
Length w/ 3-point hitch139.6 in. (3,547 mm)
Width65.7 in. (1,669 mm)
Height from Top of ROPS Cab103.1 in. (2,618 mm)
From Top of the Highest PointNA
Wheelbase75.6 in. (1,920 mm)
Ground Clearance15.7 in. (400 mm)
Front Tread Ag Tires – Min53.3 in. (1,355 mm)
Rear Tread Ag Tires – Min52.5 in. (1,324 mm)
Turning Radius w/ Brake9.97 ft. (3.04 m)
Weight w/ Ag Tires w/ Cab4,183 lbs. (1,897.4 kg)
3-POINT HITCH
Standard CategoryCategory I & II
Lift Capacity, 24″ aft of hitch, lb(kg)3,177 lbs. (1,441 kg)
Control TypePosition with Draft Control
TIRE SIZE
Agricultural
Front9.5-16
Rear16.9-24
Truf
Front29-12.5-15
Rear21.5L-16.1
Industrial
Front10-16.5
Rear17.5-24


Kioti NX6010 hst cab Tractor

Kioti NX6010 hst cab Tractor

Kioti NX6010 hst cab Tractor Key Features

  • Engine Gross Horsepower: 60 hp
  • Transmission Type: Hydrostatic
  • PTO Type: Independent
  • Shuttle:NA
  • PTO Horsepower: 48.3 hp
  • Lifting Capacity: 1441 kg

Kioti NX6010 hst cab Tractor Price

The Kioti NX6010 hst cab Tractor price will be $30,900.

Kioti NX6010 hst cab Tractor Specifications

ENGINE
Engine Model3F183T
Engine Gross Power60 hp (44.7 kW)
Rated Speed2,600 rpm
No. of Cylinders3
Fuel TypeDiesel
AspirationTurbo Charged
Displacement111.4 cu. in. (1,826 cc)
Fuel Tank Capacity14.8 gal. (56 L)
TRANSMISSION
Transmission TypeHydrostatic
ShuttleNA
Main GearNA
No. of Travel Speeds – Forward / Reverse3 Range
Min. Travel Speed of Forward w/ Ag1 @ Engine rated speed0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag1 @ Engine rated speed18.26 mph (29.38 km/h)
BrakesWet Multi Disc
ClutchNA
HYDRAULICS
PumpGear
Pump Capacity (Max. Flow Rate)17.9 gpm (67.6 L/min)
POWER TAKE OFF
PTO Type TransIndependent
PTO Power48.3 hp (36 kW)
Rear PTO Speeds(1st)540 rpm
Mid PTO Speeds2,000 rpm (Optional)
DIMENSIONS W/AG TIRE
Length w/ 3-point hitch139.6 in. (3,547 mm)
Width65.7 in. (1,669 mm)
Height from Top of ROPS Cab94.1 in. (2,390 mm)
From Top of the Highest PointNA
Wheelbase75.6 in. (1,920 mm)
Ground Clearance15.7 in. (400 mm)
Front Tread Ag Tires – Min53.3 in. (1,355 mm)
Rear Tread Ag Tires – Min52.5 in. (1,324 mm)
Turning Radius w/ Brake9.97 ft. (3.04 m)
Weight w/ Ag Tires w/ Cab4,520 lbs. (2,050.3 kg)
3-POINT HITCH
Standard CategoryCategory I & II
Lift Capacity, 24″ aft of hitch, lb(kg)3,177 lbs. (1,441 kg)
Control TypePosition with Draft Control
TIRE SIZE
Agricultural
Front9.5-16
Rear16.9-24
Truf
Front29-12.5-15
Rear21.5L-16.1
Industrial
Front10-16.5
Rear17.5-24


Kioti NX5510 Tractor Review

The Kioti X5510 is a 55-horsepower utility tractors that is popular for its dependability, efficiency and ease of use. It is a favorite option for ranchers, farmers, and other landowners that require a robust and versatile tractor that can be used for a variety of jobs. For a full review, please check this YouTube video Here.

Final Words

So this was about Kioti NX Series 5510 and 6010 Tractor hope you enjoyed reading this article and if you want to share something regarding this article you can do that by commenting below, I will reply to you as soon as possible. Thanks for reading and stay tuned with me for more stuff like this.

Subscribe
Notify of
guest

0 Comments
Inline Feedbacks
View all comments
