Force Traveller Ambulance

Force Traveller Ambulance specs

Hello, friends Hi! Welcome to our site. I hope you alright, and I am your vehicle guide is here, as usual, So today I going to introduce the Force Traveller Ambulance information such as Price List in India, Technical Specifications, Features, Images and More.

That all kinds of information is very useful to you for buy or sell this model School Bus because that all kinds of information are genuine and reliable. I hope you like it. Ok friends Let’s start it.

Force Traveller Ambulance Price

Force Traveller Ambulance 1 Force Traveller Ambulance Price is Rs.15.19 Lakh.

Force Traveller Ambulance key Features

Force Traveller Ambulance interior

  • The Force Traveller Ambulance outside look is beautiful and eye catching. It’s main features such as
  • Monocoque body structure for total safety.
  • Cathodic electrodeposition of primer coat excellent safety and enhance paint gloss retention.
  • High roof provides a clear standing height of 6 feet.

Force Traveller Ambulance interior 1

  • Low floor height for easy entry and exit.
  • Force traveller ambulance roomy interior features such as fans, hooks for IV bottles, Brackets for oxygen cylinder with suitable straps, factory made a stretcher, medicine cabinet, wailing horn and signaling tools.
  •  Seating: 7+D+patient and 8+D+patient

Force Traveller Ambulance Technical Specifications

ENGINE
Engine TD 2650 FTI ED TD 2200 Common Rail
Emission BS III BS III BSIV
Type 4 cyl, DI, TCIC 4 cyl, 16V, DOHC, VGT, Dual Mass Fly Wheel
Displacement 2596 cc 2149 cc
Max Power 58kW (82 Ps) @ 3200 rpm 95 kW (129 Ps) @ 3800 rpm
Max Torque 215 Nm @ 1800 – 2000 rpm 295 Nm @ 1600 – 2400 rpm | 300 Nm @ 1600 – 2400 rpm
TRANSMISSION
Type Synchromesh
No. of Gears 5 Forward, 1 Reverse, 5th gear Overdrive
AXLE
Front Dead Rigid, I-Beam, Reverse Elliot Type
Rear Live Rigid
SUSPENSION
Front Semi elliptical leaf springs with hydraulic shock absorbers and anti-roll bar
Rear Semi elliptical leaf springs with hydraulic shock absorbers
STEERING
Type Mech / PS (optional) Power Steering (PS)
BRAKES
Type Hydraulic, dual circuit, vacuum-assisted
Front 4-Piston, ventilated, disc brakes with wear indicator
Rear Drum Brakes
Parking Mechanical on rear wheels
Wheels & Tyres 215/75 R 15″
WARRANTY
Warranty 3 year / 3 lac km 1.5 year / 1.5 lac km
Free Services Six
DIMENSIONS
Wheel base (mm) 3050 3350
Overall Length 4935 5415
Overall Width 1975 1975
Overall Height 2250 2250
Overhang Front 900 900
Overhang Rear 985 1165
Ground Clearance 210 210
Turning Radius (m) 6 6.5
Fuel Tank Capacity(L) 70 70
Seating Capacity 7+D+1 Patient 8+D+1 Patient
WEIGHT (KG)
Max. Permissible FAW 1490 1490
Max. Permissible RAW 2020 2020
Max. Permissible GAW 3510 3510
